C2G Short Range HDMI over Cat5 Extender Kit with Auto Equalization 29298

Be the first to review this product...

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

MAIN OVERVIEW FEATURES: Connectivity Technology: WiredNumber of Input Devices Supported: 1Number of Output Devices Supported: 1Maximum Operating Distance: 160 ftGraphics Modes: Full HDMaximum Video Resolution: 1920 x 1080Network (RJ-45): YesHDMI In: YesHDMI Out: YesNumber of Network (RJ-45) Ports: 4Number of HDMI Inputs: 1Number of HDMI Outputs: 1Media Type Supported: Twisted PairTwisted Pair Cable Standard: Category 6Color: BlackTransmitter Height: 0.80"Transmitter Width: 2"Transmitter Depth: 3.10"Transmitter Weight (Approximate): 1.45 lbPackage Contents: TransmitterReceiverFoot Pad SetPower AdapterUser GuideCountry of Origin: TaiwanLimited Warranty: 3 Year

Model
Brand	C2G
Model	29298

Performance
Color	Black

Specification
Specification	Video Characteristics Maximum video resolution extension distance: Cat6 - 1080i - 160ft Cat6 -1080p - 130ft Cat5e (solid conductor) - 1080i - 160ft Cat5e (solid conductor) -1080p - 65ft Cat5e (stranded conductor) -1080i - 130ft Cat5e (stranded conductor) -1080p - 50ft Power Adapter Specifications: Input - 100~240 VAC, 50~60Hz, 0.6A Output - 12 VDC, 1.5A Cable Length - 5ft Pin Diameter - OD: 5.5mm, ID: 2.1mm Center Pin Polarity - Positive Physical Characteristics: Operating Temperature - 0~40°C, 0~80% RH (Non-condensing) Storage Temperature - 0~40°C, 0~80% RH (Non-condensing) Enclosure - Metal

Feature
Feature	The Short Range HDMI over Cat5 Extender kit is an ideal solution for extending HDMI audio/video signals beyond the typical 50 foot length limitation of a HDMI cable. This solution is able to extend HDMI up to 160 feet and requires the use of two Cat5 patch cables. Auto equalization makes installation easy regardless of the length of the Cat5 patch cables used. Simply make the HDMI and Cat5 cable connections and the transmitter and receiver will automatically adjust to optimize the video for the length of cable used. EDID pass through is supported to ensure that content is sent at the optimal resolution for the display. HDCP is supported, allowing protected content to be passed through this extension solution. The maximum resolution supported will vary depending upon the type and length of the Cat5 patch cable. Product Features Extends HDMI audio/video signals up to 160 feet Requires the use of two standard Cat5 patch cables Uses auto equalization Supports EDID pass through, HDCP and up to a 1080p resolution Kit includes both the transmitter and receiver units

Dimensions & Weight
Dimensions	0.8" x 2.0" x 3.1"
Weight	1.45 lbs.

Package Contents
Package Content	Transmitter Receiver Foot pad set Power adapter User guide

Additional Information
Date First Available	March 18, 2015

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 3 years
Limited Warranty period (labor): 3 years
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.com's 30-Day Return Policy. Read full return policy for details.
