Cisco Small Business SRW2016 Gigabit Switch with WebView

(17) Write a Review
  • 8K MAC Address Table
  • 2MB Buffer Memory
Specs
Reviews (17)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Cisco Systems, Inc. SRW2016

Model
Brand Cisco Small Business
Model SRW2016
Format & Standards
Standards IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.1q
Ports & Interface
Primary Ports 16 x 10/100/1000 RJ-45 ports and 2 shared MiniGBIC slots
Primary Port Speed 10/100/1000Mbps
Data Transmission
MAC Address Table 8K
Switching Method Store and Forward
VLAN Support Yes
Jumbo Frames Up to 9KB
Buffer Memory 2MB
Details
LEDs System, Link/Activity, Gigabits
Dimensions & Weight
Dimensions 16.9" x 1.8" x 13.8"
Weight 7.30 lbs.
Environmental
Temperature 0°C to 50°C (32°F to 122°F)
Humidity 20% - 95%, Non-condensing
Features
Features 2 MiniGBIC slots for Fiber and Copper Gigabit Ethernet expansion (Shared)
Provides flow control mechanism to ensure zero packet loss. Uses backpressure for half-duplex operation and IEEE802.3x for full duplex operation.
Provides non-blocking switching performance.
Provides Multicasting, Broadcasting and Flooding Control.
Four egress queues on all switch ports.
Support for strict priority and weighted round-robin (WRR) CoS policies
Traffic classification based on Port#, VLAN priority in VLAN tagging packet.
Supports 802.1q Tagged based VLAN for support of up to 64 VLANs
Supports up to 8 trunking groups.
Load sharing among trunk ports based on MAC address.
Port Mirroring to monitor the traffic of Mirrored ports.
ACL to limit the interface and IP domain to manage the switch
Web based configuration makes installation and setup easy

Minimum Requirements:
Cat5 Ethernet Network Cable
TCI/IP Protocol installed on each computer within the network
Network Adapter installed in each computer
Network Operating System (e.g.Windows, Linux, MacOS X)
Additional Information
First Listed on Newegg July 12, 2005

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 5 years
  • Limited Warranty period (labor): 5 years
