Arducam has been a professional designer and manufacturer of SPI, MIPI, DVP and USB cameras since 2012. We also offer customized turnkey design and manufacturing solution services for customers who want their products to be unique.
The B0205 is a new member of Arducam’s USB camera family. Based on 1/2.7” OV2710, it's a 2MP, UVC compliant, wide-angle USB 2.0 camera with a motorized IR-Cut filter and infrared LEDs. The motorized (switchable) IR-CUT filter and infrared LEDs can be triggered by the photoresistor according to the light environment to be ON/OFF to block or pass the infrared light. It can be widely used in wildlife photography, home security systems, baby cameras, etc.
No longer be anxious about installing the driver! The native UVC drivers of Windows, Linux, and Mac shall be compatible with this camera so that it does not require extra drivers to be installed.
SPECIFICATIONS
- Camera
- Sensor: 1/2.7” OV2710
- Resolution: 2MP 1920 x 1080
- Data Format: MJPG/YUY2
- Frame Rate: MJPG: 30fps@320*240, 352*288, 640*480, 800*600, 1024*768, 1280*720, 1280*960, 1280*1024, 1920*1080 YUY2: 30fps@320*240,352*288; 15fps@640*480; 20fps@800*600; 10fps@1024*768, 1280*720; 5fps@1280*960,1280*1024,1920*1080
- IR Sensitivity: Integral IR filter, switch automatically based on light condition (only visible light during the daylight and IR sensitivity during the night
- Lens
- Field of View (FOV): 105°(D) × 92°(H) × 76°(V)
- Lens Mount: M12
- Focusing Range: 3.3ft (1M) to infinity
- Functionality and Compatibility
- Adjustable parameters: Brightness, Hue, Contrast, Saturation, Sharpness, Gamma, White Balance (Manual/Auto), Gain, Backlight Comp, Exposure (Manual/Auto).
- System Compatibility: Windows, Linux, Mac, and Android with UVC.
- Power
- Power Supply: USB powered 5V
- Working Current: MAX 370mA
- Physical
- Operating Temp.: -4°F~158°F (-20°C~+70°C).
- Dimension: 38mmx38mm
- Cable Length: 3.3ft (1M)
- APPLICATIONS:
- Video conference
- Home video surveillance system
- Day&night vision security camera system
- Dashcam
- Monitoring 3D printer
- Baby Camera
- Robot and machine vision
 Arducam 1080P USB Camera, Day & Night Vision Webcam for Computer, 2MP Automat... |  Arducam 2.4MP Day & Night Vision USB Camera Module, 1080P Automatic IR-Cut Sw... |  IMX462 Day & Night Vision USB Camera |  Arducam Starvis USB Camera Module, 1080P Low Light Webcam, Mini UVC USB2.0 Li... |  Arducam 1080P IMX291 Low Light USB Camera, 120° Wide Angle Lightburn Camera M... | |
|---|---|---|---|---|---|
| Customer Reviews | — | — | — | — | — |
| Price | — | — | — | — | — |
| Sensor | OV2710 | STARVIS 2 Image Sensor | IMX462 | STARVIS 2 Image Sensor | IMX291 |
| Resolution | 2MP | 2.4MP | 2MP | 2.4MP | 2MP |
| Field of View | 105°(D) × 92°(H) × 76°(V) | 102°(D)×86°(H)×47°(V) | 95°(D)×83°(H)×67°(V) | 102°(D)×86°(H)×47°(V) | 120°(D) |
| Lens Mount | M12 | M12 | M12 | M12 | M12 |
| Frame Rate | MJPG: 30fps@320*240, 352*288, 640*480, 800*600, 1024*768, 1280*720, 1280*960, 1280*1024, 1920*1080 YUY2: 30fps@320*240,352*288; 15fps@640*480; 20fps@800*600; 10fps@1024*768, 1280*720; 5fps@1280*960,1280*1024,1920*1080 | MJPG/H.264: 1920x1080@30FPS, 1280x720@30FPS, 640x480@30FPS;YUV: 640x480@30FPS, 320x240@30FPS; 320x320@30FPS, 128x128@30FPS; 96x96@30FPS; | YUY2: 30fps320×240, 640×480 MJPG: 30fps@320×240,640×480,1280×720,1920×1080 H264: 30fps@1920×1080,1280×720, 640×480, 640×360 | MJPG/H.264: 1920x1080@30FPS, 1280x720@30FPS, 640x480@30FPS; AI Resolution: 640x480@30FPS,320x320@30FPS, 320x240@30FPS, 128x128@30FPS; 96x96@30FPS; | H.264 30fps@1920x1080; MJPG 30fps@1920x1080; YUY2 30fps@640x480 |
| IR LEDs | 6pcs 850nm IR LEDs | 8pcs 850nm IR LEDs | 6x 940nm IR LEDs | / | / |
| IR illumination distance | 3-5m | 18m | 3m | / | / |
| SKU | B0506 | B0590 | B0490 | B0576C | B0448 |
