Camera: Camera range (imperial): Up to 20 ft
Camera range (metric): Up to 6.1 m
Camera resolution: 2160p, 4K UHD (3840 x 2160)
Camera type: Single-lens
Digital Video Capture Resolution: Content video resolution (input): UHD (3840 x 2160); HD (1920 x 1080); WSXGA+ (1680 x 1050); UXGA
(1600 x 1200); SXGA (1280 x 1024); WXGA (1280 x 768); HD (1280 x 720); XGA (1024 x 768); SVGA (800 x 600)
Content video resolution (output): UHD (3840 x 2160); HD (1920 x 1080); WSXGA+ (1680 x 1050); SXGA+
(1400 x 1050); SXGA (1280 x 1024); HD (1280 x 720); XGA (1024 x 768)
Diagonal field of view (dFoV): 110°
Horizontal field of view (hFoV): 95°
People video resolution: 4K, 30 fps (TX and RX) from 2048 Kbps; 1080p, 60 fps from 1740 Kbps; 1080p, 30 fps from 1024 Kbps; 720p, 60 fps from 832 Kbps; 720p, 30 fps from 512 Kbps
Additional Features: Hear Every Voice Clearly
With RightSound technology and multiple beamforming elements in every individual mic pod, the audio focus is always automatically on the active speaker. A single mic pod provides coverage for up to ten people. Larger meeting spaces can be provisioned with up to seven mic pods working in concert to receive and transmit remarkably clear audio for every individual at the table.
Simplified Cabling
Up to 7 Rally Mic Pods can be daisy-chained together with a single cable connection to the Rally table hub. For U-shaped tables or single-wire cabling through grommets, the Rally Mic Pod Hub accessory provides three connections for optimal positioning and to bring mute control within easy reach.
Premium, Low-Profile Design
Rally Mic Pods are elegant and deceptively small for their remarkable ra...
Specification: Tap IP
Touch Screen: 10.12 in (257 mm) diagonal screen with 14° display angle
Resolution: 1280 x 800
Cabling: Power over Ethernet (PoE) cable (not included), IEEE 802.3af Type 1, Class 3 device
Cable Management: Internal cable retention and strain relief system
Ethernet: 10/100 Mbps
WiFi: 802.11a/b/g/n/ac
Device Management: Logitech Sync
Color: Graphite
Mounting: 3.94 x 3.94in (100 x 100 mm) VESA FDMI
Rally Bar Huddle
Built-in Components: 6 DMIC microphone array, digital PTZ camera, 1 full range ported speaker, cable management & retention system, multi functional mount, integrated motorized privacy shutter, Logitech CollabOS platform
Enclosure: All-in-one enclosure with field replaceable front cover
Device Management: Logitech Sync
Displa...
Camera: 12MP camera
30 frames per second
1/2.3’’ CMOS
5x digital zoom
f/2.5 aperture
120° horizontal field of view
95° vertical field of view
Auto framing (face detect)
Speaker tracking
Auto brightness and white balance
Fixed focus lens
Automatic rotation of the image when the video bar unit is mounted upside down
Frames camera mode for individual participant framing
Digital Video Capture Resolution: Video Standards:
H.263, H.264, AV1
Video Inputs:
1x HDMI input supports formats up to maximum 3840 x 2160 at 30 fps, including 1920 x 1080 at 60 fps
1x USB-C input supports formats up to maximum 3840 x 2160 at 30 fps, including 1920 x 1080 at 60 fps
Consumer Electronics Control (CEC) 2.0
Video Outputs:
2x HDMI outputs supporting formats up to 3840 x 2160 at 60 fps
Live video resolutions (encode and decod...
Camera: Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical, 3X digital available with upcoming software update)
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage: 132.1° Horizontal x 82.2° Vertical
