Dahua X82B3A 16 x BNC 16-Channel Penta-brid 4K 1U, Digital Video Recorder, No pre-installed HDD
- AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
- Manual, Schedule (Regular, Continuous), MD (Video Detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
- 16 x BNC
- None Storage Installed
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Dahua Technology X82B3A
| Brand | Dahua |
|---|---|
| Series | Pro Series |
| Model | X82B3A |
| Channel | 16 Channel |
|---|---|
| Supported Protocols | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P, IP Search (Supports Dahua IP cameras, DVRs, NVS) |
| Network Interface | One (1) RJ-45 (1000 Mbps) Port |
| Ports | One (1) USB 2.0 Port and One (1) USB 3.0 Port One (1) Port for PTZ Control |
| Video Input | 16 x BNC |
| Video Output | 1 x VGA, 1 x HDMI |
| Audio Input | 4 x RCA |
| Frame Rate | Main Stream 8 MP at 7 fps 6 MP at 10 fps 5 MP at 12 fps 4K-N, 4 MP, 3 MP at 15 fps 4M-N, 1080p, 720p, 960H, D1, CIF at 30 fps Sub Stream 960H at 15 fps; D1, CIF at 30 fps |
| Compression Format | AI Coding, Smart H.265+, H.265, Smart H.264+, H.264 |
| Recording Type | Manual, Schedule (Regular, Continuous), MD (Video Detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Video Setting | 8 MP, 6 MP, 5 MP, 4K-N, 4 MP, 3 MP, 4M-N, 1080p, 720p, 960H, D1, CIF |
| Storage Installed | None |
| Max Capacity | Two (2) SATA Ports, up to 10 TB capacity for each disk |
| Operating System | Embedded LINUX |
| Power Supply | 12 VDC, 5 A |
| Temperature | Operating Temperature: -10°C to +55°C (+14°F to +131°F) Storage Temperature: -20°C to +70°C (-4°F to +158°F) |
|---|---|
| Humidity | Operating Humidity: 0% to 90% RH Storage Humidity: 0% to 90% RH |
| Dimensions | 14.76" x 10.96" x 2.09" |
|---|---|
| Weight | 4.20 lbs. |
| First Listed on Newegg | December 01, 2022 |
|---|
