Question 1

Does this board support all 1366 CPUs such as my i7 980x? Or is it only supporting the Xeon CPUs?

Accepted Answer

Xeon, 5500 & 5600 series ONLY. If you read any of the reviews, you'd find the link to the MFG website, which lists:

5520 Series Motherboards (Dual-QPI LGA 1366)

Gainestown
        Xeon W5590 - 3.33 GHz
        Xeon W5580 - 3.20 GHz
        Xeon L5530 - 2.40 GHz
        Xeon E5507 - 2.27 GHz
        Xeon E5503 - 2.00 GHz
    Nehalem
        Xeon X5550 - 2.66 GHz
        Xeon L5520 - 2.26 GHz
        Xeon L5506 - 2.13 GHz
        Xeon E5540 - 2.53 GHz
        Xeon E5530 - 2.40 GHz
        Xeon E5520 - 2.26 GHz
        Xeon E5506 - 2.13 GHz
        Xeon E5504 - 2.00 GHz
    Westmere
        Xeon X5690 - 3.46 GHz
        Xeon X5680 - 3.33 GHz
        Xeon X5677 - 3.46 GHz
        Xeon X5670 - 2.93 GHz
        Xeon X5667 - 3.06 GHz
        Xeon X5660 - 2.80 GHz
        Xeon X5650 - 2.66 GHz
        Xeon L5640 - 2.27 GHz
        Xeon L5638 - 2.00 GHz
        Xeon L5630 - 2.13 GHz
        Xeon E5649 - 2.53 GHz
        Xeon E5645 - 2.40 GHz
        Xeon E5640 - 2.67 GHz
        Xeon E5630 - 2.53 GHz
        Xeon E5620 - 2.40 GHz
        Xeon E5607 - 2.27 GHz
        Xeon E5606 - 2.13 GHz
        Xeon E5603 - 1.60 GHz

It is unfortunate that eVGA had decided to remove the main product pace for this board, but the info is still out there if you choose to look deep enough for it.

FYI, if you search "i7 980x vs xeon", you will find that the i7 980x is almost the same as a X5680, but can't hold a candle to it in performance.

Question 2

What is the exact weight of this thing?

Accepted Answer

8.2lb

Sincerly: You'r automate gamer pc builder!

Question 3

Purchased this board months ago,  i have issues with display, after trying numerous Graphics cards....i still have the error code 85 on the onboard AMI POST...what could be the cause?

Accepted Answer

From: http:// ww w .evga .c om/ support/faq/afmviewfaq.aspx?topicid=57&faqid=59094

I get the 7F or 85 post code at boot. What does it mean?

These post codes will appear if you have a problem that would prevent your system from booting up. If you have video on the screen you would generally see a error message and have options at the bottom that state "press F1 to continue, or DEL to enter setup". Here are some of the common error messages that could appear;

CPU has been changed - This is a normal error if the board is brand new OR the processor has been replaced with a different processor.CMOS checksum error defaults loaded. - This will indicate that the motherboard bios has been reset by the CMOS reset switch or the BIOS has lost power.

If you do not have video and are getting these POST codes, It would most likely be that the video card in your system is not functioning.

In rare cases these POST codes with out video could be that the motherboard bios has been corrupted. Usually powering down and removing the CMOS battery, then letting it discharge for 10 minutes, may resolve these cases.

Here are the POST codes by chipset series.
If you are getting the 7F POST code on:

any 600 chipset series motherboardsany 700 chipset series motherboardsany x58 chipset series motherboards

If you are getting the 85 POST code on:

any P55 chipset series motherboardsany H55 chipset series motherboardsany W555 (SR2) chipset series motherboards.

Hope this helps.
