    EVGA SuperNOVA P3 220-P3-1200-X1 1200 W ATX12V / EPS12V 80 PLUS PLATINUM Certified Full Modular Active PFC Power Supply

    (70)(3) Write a Review
    • ATX12V / EPS12V
    • Full Modular
    • 80 PLUS PLATINUM Certified
    • 100 - 240 V 50/60 Hz
    • +3.3V@25A, +5V@25A, +12V@100A, -12V@0.5A, +5Vsb@3A
    🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
    +
    +
    Specs
    Reviews (70)
    avatar

    Any questions? Our AI beta will help you find out quickly.

    Try me now

    Learn more about the EVGA 220-P3-1200-X1

    General
    Brand EVGA
    Series SuperNOVA P3
    Model 220-P3-1200-X1
    Details
    Type ATX12V / EPS12V
    Maximum Power 1200 W
    Fans 135 mm Fluid Dynamic Bearing
    PFC Active
    Main Connector 24Pin
    +12V Rails Single
    PCI-Express Connector 8 x 6+2-Pin
    SATA Power Connector 12
    Max PSU Length 180 mm
    Modular Full Modular
    Energy-Efficient 80 PLUS PLATINUM Certified
    Over Voltage Protection Yes
    Input Voltage 100 - 240 V
    Input Frequency Range 50/60 Hz
    Input Current 14 - 7 A
    Output +3.3V@25A, +5V@25A, +12V@100A, -12V@0.5A, +5Vsb@3A
    MTBF >100,000 Hours
    Approvals TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
    Compliance with ErP Lot 3 2014 Requirement
    Connectors 1 x 24 Pin ATX
    2 x 8 Pin EPS (4+4)
    8 x 8 Pin PCIe (6+2)
    12 x SATA
    8 x Four-Pin Peripheral
    1 x Floppy
    Cable Spec ATX Cable: 1 x 600mm (m)
    EPS Cable: 2 x 750mm (m)
    PCIe Cable: 2 x 750mm, 900mm (m), 4 x 700mm (m)
    SATA Cable: 4 x 550mm, 650mm, 750mm (m)
    Four-Pin Peripheral Cable: 2 x 550mm, 650mm, 750mm, 850mm (m)
    Floppy Adapter: 1 x 100mm
    AC Power: 1 x 1500mm (m)
    Dimension & Weight
    Dimensions 3.40" x 5.90" x 7.09"
    Weight 9.20 lbs.
