    Extreme Networks 5320 16-Port 30W PoE Switch w/ AC power, 4 x 1/10Gb SFP+ uplink ports | 5320-16P-4XE

    Be the first to review this product...
    • 5320-16P-4XE
    • 5320-24P-8XE
    • 5320-48P-8XE
    • High Performance and Speed: The 5320-16P-4XE features 16 Gigabit Ethernet ports and 4 1/10GbE SFP+ uplink ports, providing high-speed connectivity and flexible network expansion
    • Advanced PoE Capabilities: Supports IEEE 802.3af/at standards and dynamic power allocation, efficiently powering connected devices and maximizing the number of supported devices
    • Enhanced Security: Includes features like 802.1X Network Access Control, Dynamic VLAN Assignment, and Access Control Lists (ACLs) to ensure robust network security
    • Comprehensive Management: Managed via ExtremeCloud IQ, offering advanced monitoring, policy-based automation, and traffic management capabilities for optimal network performance
    • Reliable and Easy Deployment: PoE support simplifies installation by delivering power and data over a single cable, reducing the need for additional power outlets and infrastructure
    +
    +
    Overview
    Specs
    Reviews
    avatar

    Any questions? Our AI beta will help you find out quickly.

    Try me now

    TheExtremeSwitching 5320-16P-4XEis a versatile network switch designed for edge and wiring-closet environments. It is part of the5320 Series, a high-performance, feature-rich edge switch family. It providesend-to-end secure network segmentationand advanced policy capabilities, making it a flexible choice for various deployment scenarios.

    Extreme Networks 5320 Series Universal Edge Switches

    5320 Series – Universal Edge Switches

    Extreme Networks 5320 Series Universal Edge Switches

    MANAGED SWITCHES

    Comes with a dual-persona capability, allowing you to choose your Operating System (ÓS). Either the Switch Engine (EXOS) or Fabric Engine (VOSS) OS can be selected at switch start-up or changed at a later stage.

    INSTANT ONBOARDING

    5320 Series onboarding to the cloud is a hands-off operation using zero touch provisioning. Simply connect the switch to the network, and it automatically connects to the cloud, ready to be provisioned.

    NETWORK FABRIC

    Supports Extreme's network fabric natively for network virtualization, automation, and network security. Included with the purchase of the 5320, no additional licenses or controllers are required.

    Performance and Scale

    Switch Model Max Active 10/100/1000Mb Ports Max Active 1Gb/2.5Gb/5Gb/10Gb ports Max Active 1Gb/10GbSFP/SFP+ ports* Max Active 10Gb Stacking ports** Aggregated Switch Bandwidth Max Frame Forwarding Rate
    5320-16P-2MXT-2X 16 2 2 2** 112Gbps 83.3Mpps
    5320-16P-4XE 16 0 4 2 112Gbps 83.3Mpps
    5320-16P-4XE-DC 16 0 4 2 112Gbps 83.3Mpps
    5320-24T-8XE 24 0 8 2 208Gbps 154.8Mpps
    5320-24P-8XE 24 0 8 2 208Gbps 154.8Mpps
    5320-48T-8XE 48 0 8 2 256Gbps 190.5Mpps
    5320-48P-8XE 48 0 8 2 256Gbps 190.5Mpps
    5320-24T-4X-XT 24 0 4 2 128Gbps 95.2Mpps
    5320-24T-24S-4XE-XT 24 0 24x100Mb/1Gb SFP
    4x1Gb/10Gb SFP+    		 2 176Gbps 131Mpps

    * As of versions 32.6 of Switch Engine and 9.0 of Fabric Engine, the capable ports in all 5320 switches will support 10Gb without requiring a port upgrade license.

    ** Will be supported in the future after the initial hardware release with the support of Switch Engine.

    Minimum/Maximum Power Consumption and Heat Dissipation

    Switch Model Minimum Power Consumption (W) Minimum Heat Dissipation (BTU/hr) Maximum Power Consumption (W)* Maximum Heat Dissipation (BTU/hr)**
    5320-16P-4XE 17 57 246 208
    5320-16P-4XE-DC 20 6 260 256
    5320-16P-2MXT-2X 12.5 43 218 75
    5320-24T-8XE 18 60 50 171
    5320-24P-8XE 21 70 480 375
    5320-48T-8XE 25 85 64 217
    5320-48P-8XE 30 104 924 629
    5320-24T-4X-XT 14 35 49 119
    5320-24T-24S-4XE-XT 25 96 87 328

    * Includes maximum PoE load (W) through the switch

    ** Does not include PoE load heat dissipated through external electronic load
