Foxconn A9DA-S AM3 AMD 890GX HDMI ATX AMD Motherboard
- AMD 890GX
- Phenom II / Athlon II / Sempron
- DDR3 1600(oc)/1333/1066
Specs
Reviews (50)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Foxconn A9DA-S
| Brand | Foxconn |
|---|---|
| Model | A9DA-S |
| CPU Socket Type | AM3 |
|---|---|
| CPU Type | Phenom II / Athlon II / Sempron |
| Chipset | AMD 890GX |
|---|---|
| South Bridge | AMD SB850 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 1600(oc)/1333/1066 |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| Serial ATA (SATA) | SATA III * 5 + eSATA * 1 |
|---|---|
| SATA RAID | 0/1/5/10 |
| Onboard Video Chipset | ATI Radeon HD 4290 |
|---|
| Audio Channels | 8 Channels |
|---|
| Max LAN Speed | 1Gbps |
|---|
| Back I/O Ports | 1 x D-Sub / 1 x DVI / 1 x HDMI / 1 x Optical S/PDIF Out / 1 x PS/2 / 6 x Audio Jacks / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 1.1/2.0 | 6 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394a |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 6 Ports |
| Onboard USB | 4 x USB 2.0 headers support additional 8 ports |
|---|---|
| Onboard 1394 | 1 x 1394a |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | Based on AMD 890GX chipset with AOD Extreme & SB850 Southbridge 2* PCIe x16 Gen2.0 with ATI CrossFireX and Hybrid Graphics support Onboard side port memory-128MB DDR3 1333 support, with graphics performance increasing over 15% Dual Channel DDR3 1600MHz(overclocking) support with AM3 socket Phenom II processors 100% SOLID Capacitor design and Ferrite Choke power delivery ensure a stable basis for overclocking and increased reliability Fully supports AMD OverDrive utility for overclocking, system monitoring and testing. |
|---|
| First Listed on Newegg | May 18, 2010 |
|---|
