Foxconn M61PML-K AM3 NVIDIA MCP61P Micro ATX AMD Motherboard

  • NVIDIA MCP61P
  • Phenom II
  • DDR3 1600/1333/1066
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (6)
avatar

Any questions? Our AI beta will help you find out quickly.

Learn more about the Foxconn M61PML-K

Model
Brand Foxconn
Model M61PML-K
Supported CPU
CPU Socket Type AM3
CPU Type Phenom II
Chipsets
Chipset NVIDIA MCP61P
Memory
Number of Memory Slots 2x240pin
Memory Standard DDR3 1600/1333/1066
Maximum Memory Supported 8GB
Channel Supported Dual Channel
Expansion Slots
PCI Express x16 1 x PCI Express x16
PCI Express x1 1 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
SATA RAID 0/1/0+1
Onboard Video
Onboard Video Chipset Integrated Graphics
Onboard Audio
Audio Channels 6 Channels
Onboard LAN
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 1 x COM (Serial Port) / 1 x D-Sub / 2 x PS/2 / 3 x Audio Jacks / 4 x USB 2.0/1.1
PS/2 2
COM 1
Video Ports D-Sub
USB 1.1/2.0 4 x USB 2.0
Audio Ports 3 Ports
Internal I/O Connectors
Onboard USB 4 x USB 2.0
Other Connectors 1x ATX 24-Pin power connector
1x 4-pin ATX 12V power connector
2x 4-pin CPU / System FAN connector
1x CD-in connector
1x CIR header
1x Intruder alarm
1x Front audio header
1x CMOS jumper
4x Serial ATA connectors
1x Speaker header.
1x Front panel header
Physical Spec
Form Factor Micro ATX
Dimensions (W x L) 9.6" x 8"
Power Pin 24 Pin
Features
Features NVIDIA MCP61P Supports AMD Socket AM3 processors (PhenomTMII )

Dual channel DDR3 1600/1333/1066 x 2 DIMMs, Max. 8GB

Integrated graphics Engine, Microsoft DirectX 9 compliant, Built-in a high performance 3D engine

1 x PCIe x16, 1 x PCIe x1, 2 x PCI

4 x SATA II /SATA RAID 0, 1, 0+1

5.1 channel HDA, Gigabit LAN
Additional Information
First Listed on Newegg October 10, 2012

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
