Learn more about the GeoVision ML200SLD(81-ML200-001)
| Brand | GeoVision |
|---|---|
| Model | ML200SLD(81-ML200-001) |
| Type | Electric Lock |
|---|---|
| Specifications | Voltage: DC 12V or AC 24V Current: 0.9A (start); 0.3A (standby) Lock Sensor Switch Rating: 1A at AC/DC 30V Door Status Sensor Switch Rating: 0.5A at AC/DC 30V (magnetic reed switch) Auto Relock Jumper: 0, 2.5 and 5 seconds (adjustable) Certification: CE, UL |
| Features | The ML200SLD is an electric bolt, featured with a stainless steel faceplate and a built-in voltage spike suppressor. It supports lock sensor and door status sensor functions. The fail-safe electric bolt locks the door when the power is applied, and unlocks the door when the power is removed. It can be applied to single-leaf or double-leaf doors. |
|---|
| Dimensions | 7.95" x 1.38" x1.69" |
|---|---|
| Weight | 1.98 lbs. |
| Package Contents | ML200SLD electric bolt x 1 Base bracket x 1 Base plate x 1 Extension plate x 2 M5 (15 mm ) x 5 M4 (11 mm ) x 8 Cover plate x 1 |
|---|
| First Listed on Newegg | December 26, 2012 |
|---|
