GIGABYTE A520M H AM4 AMD A520 SATA 6Gb/s Micro ATX AMD Motherboard

Used - Very Good

AMD A520
Supports AMD Ryzen 5000 Series / 3rd Gen / 3rd Gen Ryzen with Radeon
AMD Ryzen 5000 series processors:
Support for DDR4 4266(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133
3rd Gen AMD Ryzen / 3rd Gen AMD Ryzen with Radeon Graphics Processors:
Support for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133

🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available

Overview

Specs

Any questions? Our AI beta will help you find out quickly.

Try me now

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Please contact the Seller directly for warranty information. Warranty information may also be found on the Manufacturer's website.
CONTACT

Return Policies

Return for refund within: 30 days
Return for replacement within: non-replaceable
This item is covered by soft_9 Return Policy

Manufacturer Contact Info

For a directory of all our manufacturers, please click below.
Manufacturers Directory

Number of Memory Slots	2x288pin (DDR4)
Memory Standard	AMD Ryzen 5000 series processors: Support for DDR4 4266(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 3rd Gen AMD Ryzen / 3rd Gen AMD Ryzen with Radeon Graphics Processors: Support for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133
Maximum Memory Supported	64GB
Channel Supported	Dual Channel
ECC Supported	Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Memory Feature	Support for Extreme Memory Profile (XMP) memory modules

PCI Express 3.0 x16	1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
PCI Express x1	2 x PCI Express x1 slots, supporting PCIe 3.0

Serial ATA (SATA)	4 x SATA 6Gb/s
M.2	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
SATA RAID	0/1/10

Audio Chipset	Realtek Audio CODEC
Audio Channels	7.1 Channels

Onboard USB	1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers
Other Connectors	1 x CPU fan header 2 x System fan headers 1 x Addressable LED strip header 1 x RGB LED strip header 1 x Front panel header 1 x Front panel audio header 1 x Speaker header 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x Serial port header 1 x Chassis intrusion header 1 x Clear CMOS jumper

CPU Socket Type	AM4
CPU Type	Supports AMD Ryzen 5000 Series / 3rd Gen / 3rd Gen Ryzen with Radeon

Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 8.1"
Power Pin	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector

Model
Brand	GIGABYTE
Model	A520M H

Item#: 9SIC3VHKVK7485
