GIGABYTE GA-8N-SLI Quad Royal LGA 775 NVIDIA nForce4 SLI x 16 ATX Intel Motherboard
- NVIDIA nForce4 SLI x 16
- Pentium EE / Pentium D / Pentium 4 HT / Celeron D
- DDR2 667
Specs
Reviews (8)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the GIGABYTE GA-8N-SLI Quad Royal
| Brand | GIGABYTE |
|---|---|
| Model | GA-8N-SLI Quad Royal |
| CPU Socket Type | LGA 775 |
|---|---|
| CPU Type | Pentium EE / Pentium D / Pentium 4 HT / Celeron D |
| FSB | 1066/800 MHz |
| Supported CPU Technologies | Hyper-Threading Technology |
| Chipset | NVIDIA nForce4 SLI x 16 |
|---|---|
| South Bridge | MCP-04 |
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR2 667 |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express x16 | 4 x PCI Express x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 1 x PCI Slot |
| PATA | 2 x ATA100 4 Dev. Max |
|---|---|
| PATA RAID | NV RAID 0/1/0+1 JBOD |
| SATA RAID | NV RAID 0/1/0+1/5 JBOD |
| Audio Chipset | Realtek ALC850 |
|---|---|
| Audio Channels | 8 Channels |
| Max LAN Speed | 2 x 1Gbps |
|---|
| Back I/O Ports | 1 x Optical S/PDIF Out / 1 x S/PDIF Coaxial Out / 2 x PS/2 / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| LPT | 1 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394a |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Onboard 1394 | 2 x 1394a |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | This product does not support Win9X/ME |
|---|
| First Listed on Newegg | January 17, 2006 |
|---|
