FOR GIGABYTE GA-B250M-D3H Motherboard USB3.1 M2 NVME SATA6GB/S HDMI PCI-E3.0 Supports 7th/ 6th Generation Processor NO H110
REFURBISHED Product Type
- This motherboard model is GA-B250M-D3H
- The quality is original second-hand goods.(Used product 90%-80% new)
- But it is working well,we will finish100% testedbefore shipping.
- Packing include one motherboard and one metal bafflewithout CMOS battery, did not have other part.
- Please make sure you buy the right board to ensure 100% compatibility your other hardware.
- This Product is 100%Not repaired.
- This Product is 100% Original GIGABYTE
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Supports 7th/ 6th Generation Intel® Core Processors
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
Ultra-Fast M. 2 with PCIe Gen3 x4 & SATA interface
Intel® Optane Memory Ready
Triple display interfaces including High Definition Multimedia Interface
High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting
GbE LAN with cFosSpeed Internet Accelerator Software
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers
GIGABYTE UEFI DualBIOS
APP Center Including Cloud Station Utility
The parameters of Jiogia B250M-D3H
Main chipset Intel B250
Chipset Description Intel B250 chipset is used
Display chip CPU Built-in display chip (requires CPU support)
Audio chip integrated Realtek ALC892 8-channel sound chip
Nic chip Onboard Intel Gigabit NIC
Processor
CPU type seventh/sixth generation Core i7/i5/i3/Pentium/Celeron
CPU slot LGA 1151
CPU Description Intel 14nm processors are supported
Memory
DIMM Type 4 x DDR4 DIMMs
Maximum memory capacity 64GB
Memory Description Supports dual-channel DDR4 2400 (OC) or 2133MHz memory
Storage expansion
PCI-E Standard PCI-E 3.0
PCI-E slot 2 x PCI-E X16 video card slot
Two PCI slots
Storage ports 1 x M. 2 ports, 1 x SATA Express ports, and 6 x SATA III ports
I/O interface
USB port 6 x USB 3.1 port (2 built-in +4 backplane), 6 x USB 2.0 port (4 built-in +2 backplane)
Video ports 1 x VGA Port, 1 x DVI port, 1 x Display Port, 1 x HDMI port
One 8-pin power port and one 24-pin power port
Other ports 1 x RJ45 network port, 6 x audio port, 1 x PS/2 key and mouse port
The plate type
Main board type Micro ATX board type
The overall dimension is 24.4 × 22.5 cm
Software Management
BIOS performance 2x64Mbit flash
Use the authorized AMI UEFI BIOS
Support for DualBIOS
PnP 1.0 a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Other parameters
Multi-graphics card technology supports AMD Quad-GPU CrossFireX dual-card Quad crossfire technology
Support for AMD CrossFireX mixed fire technology
Power supply mode five phases
Hardware monitoring voltage detection
Temperature detection
Fan speed Detection
Over temperature warning
Fan Fault Warning
Intelligent fan control
The launch date is January 2017
Motherboard accessories
Packing List Motherboard x1+ baffle x1
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
Ultra-Fast M. 2 with PCIe Gen3 x4 & SATA interface
Intel® Optane Memory Ready
Triple display interfaces including High Definition Multimedia Interface
High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting
GbE LAN with cFosSpeed Internet Accelerator Software
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers
GIGABYTE UEFI DualBIOS
APP Center Including Cloud Station Utility
The parameters of Jiogia B250M-D3H
Main chipset Intel B250
Chipset Description Intel B250 chipset is used
Display chip CPU Built-in display chip (requires CPU support)
Audio chip integrated Realtek ALC892 8-channel sound chip
Nic chip Onboard Intel Gigabit NIC
Processor
Specifications
CPU type seventh/sixth generation Core i7/i5/i3/Pentium/Celeron
CPU slot LGA 1151
CPU Description Intel 14nm processors are supported
Memory
Specifications
DIMM Type 4 x DDR4 DIMMs
Maximum memory capacity 64GB
Memory Description Supports dual-channel DDR4 2400 (OC) or 2133MHz memory
Storage expansion
PCI-E Standard PCI-E 3.0
PCI-E slot 2 x PCI-E X16 video card slot
Two PCI slots
Storage ports 1 x M. 2 ports, 1 x SATA Express ports, and 6 x SATA III ports
I/O interface
USB port 6 x USB 3.1 port (2 built-in +4 backplane), 6 x USB 2.0 port (4 built-in +2 backplane)
Video ports 1 x VGA Port, 1 x DVI port, 1 x Display Port, 1 x HDMI port
One 8-pin power port and one 24-pin power port
Other ports 1 x RJ45 network port, 6 x audio port, 1 x PS/2 key and mouse port
The plate type
Main board type Micro ATX board type
The overall dimension is 24.4 × 22.5 cm
Software Management
BIOS performance 2x64Mbit flash
Use the authorized AMI UEFI BIOS
Support for DualBIOS
PnP 1.0 a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Other parameters
Multi-graphics card technology supports AMD Quad-GPU CrossFireX dual-card Quad crossfire technology
Support for AMD CrossFireX mixed fire technology
Power supply mode five phases
Hardware monitoring voltage detection
Temperature detection
Fan speed Detection
Over temperature warning
Fan Fault Warning
Intelligent fan control
The launch date is January 2017
Motherboard accessories
Packing List Motherboard x1+ baffle x1
