NEMIX RAM 64GB (2X32GB) DDR4 3200MHZ PC4-25600 2Rx8 1.2V 288-PIN ECC Unbuffered UDIMM KIT
NEMIX RAM 64GB (2X32GB) DDR4 3200MHZ PC4-25600 2Rx8 1.2V 288-PIN ECC Unbuffered UDIMM KIT
(15)
  •
  • $244.75 –
Sponsored

You’re seeing this ad based on the product’s relevance to your search query. If you are a seller and want to participate in this program click here to learn more.

Out of stock
  • $7,458.99
Price alert
Add to wish list
Sold by Newegg

Shipped by Newegg

Shop it at NeweggBusiness.
Shop All GIGABYTE Products

GIGABYTE S461-3T0 4U Rackmount Server Barebone 4U 60-Bay Dual Processors Storage Server (Intel)

Be the first to review this product...
  • 2nd Gen. Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
  • 6-Channel RDIMM/LRDIMM DDR4, 16 x DIMMs
  • Supports Intel® Optane™ DC Persistent Memory
  • 2 x 10Gb/s SFP+ and 2 x 1Gb/s LAN ports
  • 1 x dedicated management port
  • 60 x 3.5" SATA hot-swappable HDD bays
  • 6 x 2.5" U.2, 2 x SATA/SAS SSD hot-swappable SSD bays in rear side
  • SAS expander with 12Gb/s transfer speed
  • 3 x PCIe Gen3 expansion slots
  • Aspeed® AST2500 remote management controller
  • Dual 2000W 80 PLUS Platinum redundant power supply
This item is covered under the Manufacturer Only Return Policy.
+
+
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the GIGABYTE S461-3T0

General
Brand GIGABYTE
Model S461-3T0
Form Factor 4U Rackmount
Workload Storage Server
CPU Supported
CPU Type Supports 2nd Generation Intel Xeon Scalable and Intel Xeon Scalable Processors
Supports Intel Xeon Platinum Processor, Intel Xeon Gold Processor, Intel Xeon Silver Processor and Intel Xeon Bronze Processor
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable
CPU Socket LGA 3647
Installed CPU No CPU Installed
Max Processors 2
Memory Supported
Memory Slots 16 x 288Pin
Installed Memory Size No Memory Installed
Memory Type Supported DDR4 3200
Channel Supported 6 Channel
Storage Supported
Installed HDD No Storage Installed
M.2 1 x Mezzanine card slot:( Reserved)
- PCIe Gen3 x8
- From CPU_0
- Optional for OCP mezzanine card with low profile type
- CPU TDP is limited to 105W if using OCP slot
Graphics
GPU/VPU Aspeed AST2500
Expansion Slots
PCI Express Slot_7 (PCIe_4): 1 x PCIe x16 (Gen3 x16 bus) slot from CPU_1
Slot_6 (PCIe_3): 1 x PCIe x16 (Gen3 x16 bus) slot from CPU_1
Slot_5 (PCIe_2): 1 x PCIe x16 (Gen3 x16 bus) slot from CPU_1
Slot_4 (PCIe_1): 1 x PCIe x16 (Gen3 x16 bus) slot from CPU_0, occupied by NVMe 4 x U.2 ports
Communications
First LAN QLogic QL41102
Max. LAN Speed 10 Gigabit + 1 Gigabit
Expansion Bays
Hot-Swap Bays Front side: 60 x 3.5" SATA/SAS hot-swappable HDD bays
Rear side: 8 x 2.5" hot-swappable SSD bays*

NOTE:
* 6 x hybrid ports and 2 x SATA/SAS ports only
* For rear side 2.5" bays support Solid State Drives only due to thermal consideration
* Please select Enterprise SATA hard drives
Panel Ports
Front USB 2 x USB 3.0
VGA 1
Rear USB 2 x USB 3.0
RJ45 2 x RJ45
1 x MLAN
Other Ports 2 x SFP+

Internal I/O
2 x SATA 7-pin connectors
1 x TPM header
1 x VROC connector
Power Supply
Max. Power 2 x 2000W redundant PSU, 80 PLUS Platinum
System
System Compatibility For Skylake processors:
Windows Server 2012 R2 with Update
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 6.9 (x64) or later
Red Hat Enterprise Linux 7.3 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
SUSE Linux Enterprise Server 11.4 (x64) or later
SUSE Linux Enterprise Server 12.2 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 16.04.1 LTS (x64) or later
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 or later
VMware ESXi 6.7 or later
VMware ESXi 7.0 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.4.0 or later
Citrix Hypervisor 8.0.0 or later

For Cascade Lake processors:
Windows Server 2012 R2 with Update
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 7.6 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
SUSE Linux Enterprise Server 12.3 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 Update2 or later
VMware ESXi 6.7 Update1 or later
VMware ESXi 7.0 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.5.0 or later
Citrix Hypervisor 8.0.0 or later
Environment
Temperature Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C
Humidity Operating humidity: 8%-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
Dimensions & Weight
Dimensions 17.24" x 6.93" x 39.45"
Weight 127.87 lbs.
Additional Information
First Listed on Newegg October 18, 2022

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
  • Read full details

Return Policies

  • Return for refund within - Contact Manufacture for Assistance
  • Return for replacement - Contact Manufacture for Assistance
  • This item is covered by Newegg.com's Manufacturer Only Return Policy. Read full return policy for details.
