GIGAIPC QBi-N97B Embedded Compact Board with Intel Processor N97, Single Channel DDR4 memory, 1 x COM, 1 x SATA 6Gb/s, 6 x USB, TPM on board - OEM
- Embedded IPC Motherboard
- Intel Processor N97
- Single Channel DDR4, 1 x SO-DIMM
- 2 x GbE LAN Ports
- 1 x SATA 6Gb/s Port
- 3 x HDMI Ports for multiple display
- 1 x COM Port (RS-232)
+
+
Overview
Specs
Reviews
See all Q & A
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-626-854-9338
- Support Website
- View other products from GIGABYTE
LOADING...
The GIGAIPC QBi-N97B is a compact embedded motherboard with an Intel N97 processor, designed for industrial and embedded PC builds that need three independent HDMI displays, dual Gigabit Ethernet, and an RS-232 serial port.
Recommended For
- Digital-signage and information-display integrators who need one compact board to drive up to three independent HDMI displays.
- Kiosk and embedded-control builders who need an RS-232 connection for legacy peripherals, plus onboard TPM 2.0 for platform security.
- Compact edge-computing or light network-appliance builders who can use the N97’s four cores, low 12 W TDP, and two Gigabit Ethernet ports.
- Small industrial-PC integrators who need a 10 × 10 cm embedded board with a wide-range 12–24 V DC input and watchdog-timer support.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Embedded computing builds needing an Intel N97 processor, dual Gigabit Ethernet, HDMI outputs, and an RS-232 connection |
| Processor | Embedded Intel Processor N97 |
| Memory | One 260-pin DDR4 slot, supporting DDR4-3200 and up to 16GB |
| Storage And Expansion | One SATA 6Gb/s port and one M.2 2280 M-Key slot supporting PCIe Gen 3x1 or SATA; one M.2 2230 E-Key slot |
| Networking | Two RJ45 Gigabit Ethernet ports with a Realtek RTL8111H LAN chipset |
| Ports And Connectivity | Three HDMI ports, one RS-232 COM port, four USB 3.2 Gen 2x1 ports, and one combo headphone/headset audio jack; also includes two USB 2.0 headers |
| Audio | Realtek ALC269 audio chipset with a combo headphone/headset jack and speaker-out header |
| Power And Internal Connectors | 12–24V DC screw-type input, 2-pin power connector, SATA power header, CPU fan header, and front panel header |
| Form Factor And Dimensions | 10 × 10 motherboard; 4.13 × 4.33 inches |
| Model Identifiers | GIGAIPC QBi-N97B |
