B660 Motherboard+Thermal Grease+SATA Cable LGA1700 12Th/13Th CPU 2XDDR4 RAM Slot HD+DP+VGA PCIE 16X SATA3.0 Motherboard

Feature: 1, Extended
Inderface: 2 x M2 22110 NVME PCIEX4 4.0; 1 x VGA + HDMI-compatible+DP; 4 x USB 3.2 Gen2x1; 2x USB 2.0; 1xNetwork interface
2,
Support on-board M2 NVME with expansion Slots: 1 xPCI-Express 5.0 x16; 1 xPCI-Express 3.0X 4
3, Dual-channel DDR4 memory slot Support Dual channel DDR4 3200/2933/2666/2400MHz
4, Designed for high-performance and enhanced capabilities you need to your server.
5, The B660 D4 M-ATX motherboard supports 12th generations of DDR4. Memory capacity up to 64GB, Memory
type: 2xDDR4, specialied in large-scale games easy to deal with large-scale film and television modeling and rendering.

Specifications

:
Product name: Desktop PC motherboard
Material: PCB
Colour: Black
Model: B660
Chipset: B660 Chipset
CPU: LGA1700, supporting 12/13 generation CPU
Memory: 2 x DDR4 memory, frequency support 3200/2933/2266/2400MHz, maximum support 64GB
Display interface: HDMI-compatible/DP/VGA
Hard disk: 3 x SATA 3.0 interface, 2 x M. 2 interface, 1 x M. 2 WIFI interface
Built in interface:
1 x F_ USB pin
1 x USB 3.0 pin
1 x F_ AUDIO pin
1 x J_ SPK pin
1 x JCMOS initial BIOS restore pin
1 x CPU_ FAN pin
2 x CSYSFAN pin
External interface:
USB interface: 2 x USB 2.0, 4 x USB 3.0
Keyboard/mouse: support 1 x PS/2 keyboard and mouse interface
AUDIO: 1 x F_ AUDIO standard audio three in one high fidelity audio interface
Expansion bus: 1 x COM pin, 1 x PCIE_ 16X and 1 x PCIE X1 interface
Power interface: 8Pin ATX12V, 24Pin ATXPWR
Product size: 24 x 19cm
Different production batches, the appearance or interface will be slightly different, which will not affect the use
Package Contents:
1 x B660 motherboard
1 x SATA cable
1 x thermal grease
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
