Add four external PCI expansion card slots to a desktop or laptop computer system
PCI Expansion Chassis
External PCI slot
PCI Express to PCI Expansion Box
System Bus Extender
System Bus Extender
External Expansion Enclosure
+
+
Overview
Specs
Reviews (2)
StarTech PEX2PCI4. Brand NewIncludes 2 Year Warranty. . Product # PEX2PCI4. . StarTech.com's innovative PCI Express to PCI Expansion Chassis provides a quick and simple solution to I/O expandability on almost any PCI Express (PCIe) enabled system. Adding external PCI slots to a server/workstation or laptop, this cost-effective and time-saving method of simply adding additional PCI cards to a server/workstation or providing a platform to be able to swap PCI add-in cards between a mobile and desktop setup is the optimal method of maximizing the I/O capabilities of new or existing systems.The external expansion chassis adds four PCI slots (32-bit/33MHz) to the host computer system, through a single PCI Express connection. Providing total bandwidth of up to 250MBps from the x1 PCIe host controller card, which allows the host computer to function as though the cards in the expansion chassis were connected directly to the motherboard.For mobile applications, the Expansion Chassis can be connected to an ExpressCard enabled laptop using StarTe
Learn more about the STARTECH PEX2PCI4
Model
Brand
StarTech.com
Model
PEX2PCI4
Details
Type
PCI Express to PCI Card
Features
Features
Add four external I/O expansion card slots to a desktop or laptop computer system. StarTech.com''s PCI Express to PCI Expansion Chassis is a quick and simple solution to I/O expandability on almost any PCI Express (PCIe) enabled system. Adding external PCI slots to a server/workstation or laptop, this cost-effective and time-saving method of simply adding additional PCI cards to a server/workstation or providing a platform to be able to swap PCI add-in cards between a mobile and desktop setup is the optimal method of maximizing the I/O capabilities of new or existing systems.
The external expansion chassis adds four PCI slots (32-bit/33MHz) to the host computer system, through a single PCI Express connection. Providing total bandwidth of up to 250MBps from the x1 PCIe host controller card, which allows the host computer to function as though the cards in the expansion chassis were connected directly to the motherboard.
Convert a single PCI Express slot to four additional external PCI slots without any driver or software installation required
External expansion enclosure simplifies swapping PCI cards, without ever having to move or take apart the main desktop/server
Backed by a StarTech.com 1 year warranty and free lifetime technical support
Dimensions & Weight
Weight
5.76
Manufacturer Warranty
Parts
1 year limited
Labor
1 year limited
Additional Information
Date First Available
November 02, 2010
