MSI B450M BAZOOKA PLUS AM4 AMD B450 SATA 6Gb/s USB 3.1 HDMI Micro ATX AMD Motherboard

AMD B450
Support AMD Ryzen 1st and 2nd Generation/ Ryzen with Radeon Vega Graphics Processors for Socket AM4
Supports 2667/ 2400/ 2133/ 1866 (by JEDEC)
Supports 3333/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 (by A-XMP OC MODE)

Specs

Reviews

Learn more about the MSI B450M BAZOOKA PLUS

Model
Brand	MSI
Model	B450M BAZOOKA PLUS

Supported CPU
CPU Socket Type	AM4
CPU Type	Support AMD Ryzen 1st and 2nd Generation/ Ryzen with Radeon Vega Graphics Processors for Socket AM4

Chipsets
Chipset	AMD B450

Memory
Number of Memory Slots	4x288pin (DDR4)
Memory Standard	Supports 2667/ 2400/ 2133/ 1866 (by JEDEC) Supports 3333/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 (by A-XMP OC MODE)
Maximum Memory Supported	64GB
Channel Supported	Dual Channel

Expansion Slots
PCI Express 3.0 x16	1 x PCIe 3.0 x16 slot - Supports x16 speed with AMD Ryzen 1st and 2nd Generation processors - Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors
PCI Express x1	2 x PCIe 2.0 x1 slots

Storage Devices
Serial ATA (SATA)	4 x SATA 6Gb/s
M.2	1 x M.2 slot (M2_1, Key M) Supports PCIe 3.0 x4 and SATA 6Gb/s 2242/2260/2280/22110 storage devices
SATA RAID	0/1/10

Onboard Video
Onboard Video Chipset	Onboard Graphics: - 1 x DVI-D port, support a maximum resolution of 1920x1200@60Hz* - 1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160@30Hz, 2560x1600@60Hz* * Only support when using AMD Ryzen with Radeon Vega Graphics Processors - Maximum shared memory of 2048MB

Onboard Audio
Audio Chipset	Realtek ALC892
Audio Channels	7.1 Channels

Onboard LAN
LAN Chipset	Realtek RTL8111H
Max LAN Speed	1Gbps

Internal I/O Connectors
Onboard USB	2 x USB 2.0 connectors (support additional 4 USB 2.0 ports) 2 x USB 3.1 Gen1 connectors (support additional 4 USB 3.1 Gen1 ports)
Other Connectors	1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 2 x 5050 RGB LED strip 12V connectors 1 x TPM module connector 1 x Front panel audio connector 2 x System panel connectors 1 x Chassis Intrusion connector 1 x Clear CMOS jumper 1 x Serial Port connector 1 x Parallel Port connector

Physical Spec
Form Factor	Micro ATX
LED Lighting	RGB
Dimensions (W x L)	9.6" x 9.6"
Power Pin	1 x 24-pin ATX 12V power connector 1 x 8-pin ATX 12V power connector

Features
Features	Supports AMD Ryzen 1st and 2nd Generation/ Ryzen with Radeon Vega Graphics Processors for Socket AM4. Supports DDR4 Memory, up to 3333+(OC) MHz. Supports ECC UDIMM memory. Lightning Fast Game experience: 1 x TURBO M.2, Store MI technology. Extended Heatsink Design: MSI extended PWM and enhanced circuit design ensures even high-end processors to run in full speed. Core Boost: With premium layout and fully digital power design to support more cores and provide better performance. DDR4 Boost: Advanced technology to deliver pure data signals for the best gaming performance and stability. Audio Boost: Reward your ears with studio grade sound quality for the most immersive audio experience. Mystic Light and Mystic Light Sync: 16.8 million colors / 10 effects in one click. Synchronize RGB strips and other RGB solutions for customization. BIOS FLASHBACK+: Simply use a USB key to flash any BIOS within seconds, without installing a CPU, memory or graphic cards. PCI-E Steel Armor: Protecting VGA cards against bending and EMI. VR Ready: Best virtual reality game experience without latency, reduces motion sickness. In-Game Weapons: Game Boost, GAMING Hotkey, X-Boost. EZ Debug LED: Easiest way to troubleshoot.

Additional Information
Date First Available	December 06, 2018
