Elo Touch E273226 1517L 15-inch iTouch Desktop Touch Screen Monitor
- 700:1
- Serial/USB
- Horizontal: +/-80° or 160° total
- Vertical: +/-70° or 140 ° total
+
+
Overview
Specs
Reviews
MAIN OVERVIEW FEATURES:
- Viewable Screen Size: 15"
- Screen Mode: XGA-2
- Response Time: 16 ms
- Aspect Ratio: 4:3
- Mount Type: Desk Mountable, Wall Mountable, Pole Mount
- Backlight Technology: LED
- Horizontal Frequency: 80 kHz
- Maximum Resolution: 1024 x 768
- Color Supported: 16.2 Million Colors
- Contrast Ratio: 700:1
- Brightness: 250 cd/m²
- Touchscreen Type: Surface Acoustic Wave
- USB: Yes
- VGA: Yes
- Operating Power Consumption: 12 W
- Color: Black
- VESA Mount Compatible: Yes
- VESA Mount Standard: 75 x 75
- Height: 9" ( 228.60 mm)
- Width: 19" ( 482.60 mm)
- Height with Stand: 12.50" ( 317.50 mm)
- Width with Stand: 14.10" ( 358.14 mm)
- Depth with Stand: 7.80" ( 198.12 mm)
- Weight (Approximate): 4.30 kg
- Package Contents:
- 1517L Rev B 15-inch Multifunction Desktop
- Detachable Touch and Video Cables
- Power Cable
- Environmentally Friendly: Yes
- Environmental Certification: RoHS, WEEE, China RoHS
- Limited Warranty: 3 Year
Elo 1517L 15-inch Multifunction Desktop Touchmonitor
- Sleek and thin design with "Built for Touch" Reliability
- 60% Energy Savings using LED Technology
- 3 Year Standard Warranty
- Integrated cable management
- Space-saving design
The 1517L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems are found.
The 1517L is offered with AccuTouch five-wire resistive, IntelliTouch or iTouch zero-bezel surface acoustic wave technology. AccuTouch is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food and grease. IntelliTouch and iTouch pure glass surface acoustic wave technology delivers the ultimate in optical quality for dry retail and hospitality applications.
The optional 3-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.
The 1517L touchmonitor is environmentally friendly, lightweight and uses less power with state-of-the-art LED backlights in the display panel.
Features:
- Sleek and thin design with "built for touch" reliability.
- Flexible and space-saving.
- 60% Energy savings using LED technology.
- Zero-bezel touchscreen versions for a smooth, easy-to-clean surface.
- Antiglare or Clear glass.
- Removable base and mounting options including VESA, wall and pole-mounting for installation flexibility and capped through-mount holes on base for table-top security.
- 15" diagonal active matrix TFT LED-backlit LCD.
- Active Display Area: 11.97 x 8.98 inches/304 x 228 mm.
- 4:3 aspect ratio.
- 1024 x 768 native resolution. Other resolutions supported.
- USB and RS232 serial connections.
- Touch technology: AccuTouch (single- touch), IntelliTouch (single-touch) and iTouch (single-touch).
- Typical power consumption: 12W, internal and external power options.
- Warranty: 3 years standard.
Key Applications
- Point-of-Sale
- Point-of-Information
Part Numbers
| Part Number | Technology | Interface | Bezel | Surface Treatment | Color | Availability |
| E523163 | AccuTouch | Serial/USB | Yes | Antiglare | Black | Worldwide |
| E532051 | AccuTouch | Serial/USB | Yes | Antiglare | White | Worldwide |
| E144246 | AccuTouch | Serial/USB | No | Antiglare | Black | Worldwide |
| E590483 | AccuTouch | Serial/USB | No | Antiglare | White | Worldwide |
| E344758 | IntelliTouch | Serial/USB | Yes | Antiglare | Black | Worldwide |
| E579160 | IntelliTouch | Serial/USB | Yes | Antiglare | White | Worldwide |
| E829550 | iTouch | Serial/USB | No | Clear | Black | Worldwide |
| E342516 | iTouch | Serial/USB | No | Clear | White | Worldwide |
| E273226 | iTouch | Serial/USB | No | Antiglare | Black | Worldwide |
| E236309 | iTouch | Serial/USB | No | Antiglare | White | Worldwide |
External Elo Peripherals
| Peripheral | Interface | Color | Part #(RoHS Compliant) |
| Magnetic Stripe Reader | USB | Black | E500356 |
| Magnetic Stripe Reader | USB | White | E233227 |
