BANNER T30UXDB All Purpose Photoelectric Sensor New
- BANNER T30UXDB All Purpose Photoelectric Sensor New
+
+
Overview
Specs
Reviews
T30UX Series w/ Discrete Output
Range: 200 mm to 2 m; Input: 10 to 30V dc
Output: NPN PNP NO NC selectable
2 m (6.5 ft) Cable
Part Number: 79998
Sensing Beam Ultrasonic
Cable Length (m) 2
PC Configurable No
Sensing Mode (General) Proximity
Sensing Mode (Detailed) Time of Flight
Housing Style Barrel
Device Type Sensor
Primary Housing Material PBT
Input/Output Discrete
Indicator LED(s)
Connection Cable
Analog Resolution/Discrete Repeatability 0.1% of distance (1.0 min)
Quick Disconnect Type No QD
Max Sensing Distance (mm) 2000
Minimum Sensing Distance (mm) 200
Sensing Beam Ultrasonic
Power Supply 10-30 V dc
Delay at Power-up (ms) 500
Adjustments Teach Button
Temperature Effect (mm/°C) 0.02% of sensing distance/°C
Number of Pins 4
Vibration MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
Mechanical Shock IEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave
Output Saturation Voltage NPN Outputs < 1.6 V at 100 mA
Output Saturation Voltage PNP Outputs < 3 V at 100 mA
Max Discrete (Switched) Output (mA) 100
Discrete (Switched) Outputs 1 NPN/PNP Configurable
Output Protection Protected against short circuit conditions
IP Rating IP67
NEMA Rating NEMA 6
Max Operating Temperature (°C) 70
Min Operating Temperature (°C) -40
Max Op. Relative Humidity Non-Condensing (%) 95 at 50°C
Warm-up Time (minutes) 15
Minimum Response Time (ms) 92
Rep Rate (ms) 30
Barrel Diameter (mm) 30
Minimum Window Size (mm) 10
Remote Teach and Laser Control Input Impedence 55 k?
Discrete Output Hysteresis (mm) 3
Ultrasonic Frequency (kHz) 174
Max Off-state Leakage Current (µA) NPN: < 200 at 30 V dc; PNP: < 10 at 30 V dc
Power/Current Consumption (exclusive of load) 40 mA
Supply Protection Circuitry Protected against reverse polarity and transient overvoltages
Feature: Remote Teach Yes
Feature: Clear Object Detection Yes
Feature: Timing (Hold/Delay) No
Feature: Chemical Resistant No
Application: Ultrasonic Yes
Common Ethernet Protocol No
IO Link No
PROFINET No
RS-232 No
RS-422 No
RS-485 No
SSI No
Wireless No
1-wire Serial Interface No
Profibus No
Range: 200 mm to 2 m; Input: 10 to 30V dc
Output: NPN PNP NO NC selectable
2 m (6.5 ft) Cable
Part Number: 79998
Sensing Beam Ultrasonic
Cable Length (m) 2
PC Configurable No
Sensing Mode (General) Proximity
Sensing Mode (Detailed) Time of Flight
Housing Style Barrel
Device Type Sensor
Primary Housing Material PBT
Input/Output Discrete
Indicator LED(s)
Connection Cable
Analog Resolution/Discrete Repeatability 0.1% of distance (1.0 min)
Quick Disconnect Type No QD
Max Sensing Distance (mm) 2000
Minimum Sensing Distance (mm) 200
Sensing Beam Ultrasonic
Power Supply 10-30 V dc
Delay at Power-up (ms) 500
Adjustments Teach Button
Temperature Effect (mm/°C) 0.02% of sensing distance/°C
Number of Pins 4
Vibration MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
Mechanical Shock IEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave
Output Saturation Voltage NPN Outputs < 1.6 V at 100 mA
Output Saturation Voltage PNP Outputs < 3 V at 100 mA
Max Discrete (Switched) Output (mA) 100
Discrete (Switched) Outputs 1 NPN/PNP Configurable
Output Protection Protected against short circuit conditions
IP Rating IP67
NEMA Rating NEMA 6
Max Operating Temperature (°C) 70
Min Operating Temperature (°C) -40
Max Op. Relative Humidity Non-Condensing (%) 95 at 50°C
Warm-up Time (minutes) 15
Minimum Response Time (ms) 92
Rep Rate (ms) 30
Barrel Diameter (mm) 30
Minimum Window Size (mm) 10
Remote Teach and Laser Control Input Impedence 55 k?
Discrete Output Hysteresis (mm) 3
Ultrasonic Frequency (kHz) 174
Max Off-state Leakage Current (µA) NPN: < 200 at 30 V dc; PNP: < 10 at 30 V dc
Power/Current Consumption (exclusive of load) 40 mA
Supply Protection Circuitry Protected against reverse polarity and transient overvoltages
Feature: Remote Teach Yes
Feature: Clear Object Detection Yes
Feature: Timing (Hold/Delay) No
Feature: Chemical Resistant No
Application: Ultrasonic Yes
Common Ethernet Protocol No
IO Link No
PROFINET No
RS-232 No
RS-422 No
RS-485 No
SSI No
Wireless No
1-wire Serial Interface No
Profibus No
