Crown XTI1002 Power Amplifier 275W @ 8 Ohms Power Amp

XTi-1002 XTi-2002 XTi-4002 XTi-6002 2 Stereo (per ch.) 700W 1000W 1600W 3000W 4 Stereo (per ch.) 500W 800W 1200W 2100W 8 Stereo (per ch.) 275W 475W 650W 1200W 8 Bridge-Mono 1000W 1600W 2400W 4200W 4 Bridge-Mono 1400W 2000W 3200W 6000W

Crown XTI 1002

The Crown XTi Series
There's no debate â?? when you choose Crown's XTi 2 Series, you're choosing one of the most powerful and innovative amplifiers on the market today. That's because the all-new XTi 2 Series amps continue to set the standard for unmatched performance and value, delivering the goods night after night without breaking a sweat.

Next Generation Features

Peakx Plus Limiters provide the ultimate in system performance and protection by allowing full control over threshold, attack, and release
Enhanced Subharmonic Synth section provides user control over frequency, gain and filter type for system-specific tuning
3 User-defined fan mode controls â?? normal, early and fullspeed â?? for matching fan performance to a specific application
New system monitoring provides software visibility of AC line voltage and power supply temperature
Integrated cast-aluminum handles for easy handling and enhanced durability
Locking power cord clip provides a secure connection between the amplifier and power cord
Updated HiQnet System Architectâ?¢ control software
Increased number of presets to a total of 50; 49 of which are user definable

Crown's Integrated Processing

Input EQ
6 parametric filters per channel with adjustable Q, ±15 dB boost/cut. Also adjustable high and low shelving filters. This 8-filter EQ section can be bypassed.

Crossover Filters
Highpass and Lowpass per channel. Butterworth 6/12/18/24 dB per octave. Linkwitz-Riley 24/48 dB per Octave. Also includes ± 15 dB bandpass gain and polarity control.

Output EQ
8 parametric filters per channel with adjustable Q, ±15 dB boost/cut. This 8-filter EQ section can be bypassed.

Delay
For signal alignment of driver; 50 mS of total delay.

SubHarmonic Synth
Takes the low-frequency content of the input signal and "synthesizes" a new signal that is the same as the input signal but one octave lower. The new synthesized signal is then mixed with the original signal to create the effect. New: Users now have control over frequency, gain, and filter type.

Peakx Plus Limiter
User defeatable limiter that allows users to control Threshold, Attack, and Release times.

Presets
50 total presets, 49 of which are user-definable.

The XTI Series Performance

Sensitivity (for full rated power at 4 ohms)
1.4 Vrms

Frequency Response (at 1 watt, 20 Hz - 20 kHz)
+0 dB, â??1 dB

Signal-to-Noise Ratio (below rated 1kHz power at 8 ohms)
XTi1002/2002/4002: 100 dB (A weighted)
XTi6002: 103 dB (A weighted)

Total Harmonic Distortion (THD)
< 0.
