1. Supports for Intel Core i7/i5/i3/E3 LGA1150 pin series processors
2. Support 4 SATA interfaces and 8 USB interfaces
3. Support high-speed
DDR3 dual channel memory slot: 1066/1333/1600MHz, maximum Capacity 16G memory
4. Support 5.1 channel ALC662 chip
5. The transmission speed of high-speed USB 3.0 interface is improved again
6. Support PCIE expansion slot * 1
7. RJ45 Gigabit network card interface
8. 4-layer PCB backplane, 3-phase power supply
9. Support Win7 and Win10 32/64 bit operating systems
Product name: computer motherboard
Model: B85
Processor: for Intel Core i7/i5/i3/E3 LGA1150 pin series processor
Chipset: eight series chipset
Memory:
Technology: dual channel DDR3 1066/1333/1600/1866MHz
Maximum capacity: 16GB
Memory slot: 2 * 240 PIN ECC/DDR3
Post I/O:
PS/2 interface: 1 * (PS/2 mouse, PS/2 keyboard)
Display interface: 1 * VGA; 1 * HDMI-compatible
Ethernet: 1 * Gigabit network card, RTL8111H network card chip
USB port: 2 * USB 3.0; 2*USB 2.0
Audio: 1*(Mic-in, Line-out, Line-in)
Internal connectors:
USB 2.0: 2 * (one FUSB can be connected to two USB 2.0 interfaces);
USB 3.0: 2 * (one FUB can be connected to two USB 3.0 interfaces) Optional
PCIe: 1* (1*PCIe x16)
ATXPWR interface: 1 * standard 1x8PIN power socket; 1 * Standard 1x24PIN power socket
Audio: 1 * 2x5Pin pin
Product size: 170 mm x 170 mm
Colour: black
Material: PCB+Metal
Package Contents:
1 x B85 motherboard
1 x SATA cable
1 x baffle
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
