Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI, VGA
Chipset ID: ITE - IT6222
Audio Specifications: HDMI output: 5.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz (VGA)
Maximum Digital Resolutions: 3840 x 2160 @ 30Hz (HDMI)
Supported Resolutions:
Maximum HDMI output:3840 x 2160 @ 30Hz
Maximum VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: Genesys Logic - GL3523 (USB Hub), Realtek - RTL8153 (LAN), Parade Technologies - PS176 (HDMI)
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type: 1 - USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.10 to 10.12 / Chrome OS
Note:
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP alt mode.
A 4K-capable display is required to achieve 4K x 2...
Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0) / 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 3840 x 2160p (HDMI)
Type and Rate USB: 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.9 to 10.12 / Chrome OS
Power Source: USB-Powered
Output Connector: 1 x USB Type-C (24 pin) USB 3.0 Male
1 x HDMI (19 pin) Female
1 x RJ-45 Female
2 x USB Type-A (9 pin) USB 3.0 Female
1 x USB Type-C (24 pin) USB 3.0 Female
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
Genesys Logic - GL3523
Realtek - RTL8153
Eton Technology - EJ899T
Parade Technologies - PS176
ITE -IT6516
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Analog Resolutions: 1920 x 1200p @ 60Hz (VGA)
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p @ 30Hz (HDMI)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 to 10.14
Chrome OS
Specifications: Audio: Yes
Chipset ID: NXP - PTN5100 / Pericom - PI3DPX1203
Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 4K (3840 x 2160) @ 60 Hz
Supported Resolutions:
1024 x 768
1280 x 720
1920 x 1080 @ 144hz
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160 @ 60Hz
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Connector:
1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x Mini-DisplayPort (20 pin) Female Output
System and Cable Requirements:
Your USB-C device must support DisplayPort over USB-C (DP alt mode) to work with this adapter
This adapter outputs a single-mode Mini DisplayPort signal and will not work with additional video adapters such as Mini DisplayPort to HDMI, Mini DisplayPor...
Specifications: Adapter Style: Adapter
Audio: Yes
Cabling: HDMI
Chipset ID: MS9282
Converter Type: Format Converter
Output Signal: HDMI
Connector A:
1 x VGA (15 pin; High Density D-Sub) Male
1 x USB A (4 pin) Male
Connector B:
1 x HDMI (19 pin) Female
Wide Screen Supported: Yes
Color: Black
Enclosure Type: Plastic
Humidity: 40%-85%RH
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -10°C to 70°C (14°F to 158°F)
OS Compatibility:
Windows 8/8.1 (32/64)
Windows 7 (32/64)
Windows Vista (32/64)
Windows XP (32/64)
Maximum Analog Resolutions: 1920x1080
Maximum Digital Resolutions: 1920x1080
Supported Resolutions:
1920x1080 (1080p)
1680x1050 (WSXGA+)
1600x1200
1600x900
1440x900
1400x1050 (SXGA+)
1366x768
1360x768
1280x1024
1280x960
1280x800
1280x768 (WXGA)
1280x720p (720p)
1280x600
1152...
Specifications: Converter Type: Format Converter
Industry Standards: HDMI, HDCP
Audio Specifications: 2 Channel
Maximum Analog Resolutions:1920 x 1200
Enclosure Type: Plastic
Humidity: 40% - 85% RH
Operating Temperature: 0 degree C to 60 degree C (32 degree F to 140 degree F)
Storage Temperature: -10 degree C to 70 degree C (14 degree F to 158 degree F)
Connector A: 1 - USB Micro-B (5-pin) Female
1 - HDMI (19-pin) Male
