SIIG, Inc Audio Video Converters

• Type: DP to HDMI
• Color: Black
• Cable Length: 9.0" +/- 0.5" (230mm +/- 13mm)
• Specifications: Quad-shielded cable with PVC jacket for maximum audio/video performance & prevention of signal loss Display modes: PC VGA, SVGA, XGA, SXGA, & UXGA display modes HDTV: 480i, 576i, 480p, 576p, 1080i & 1080p Supports multi-channel digital audio (system's DisplayPort must support audio) AC to DC level trigger - requires dual-mode Display Port source RoHS compliant
• Model #: CB-DP0062-S1

• Type: DP to VGA
• Color: Black
• Specifications: Chipset: ANX9832 Compliant with DisplayPort 1.1a receiver Configurable 1 or 2 lane operation Supports 1.62 and 2.7Gbps data rates Supports Down Spread Spectrum (SSC) Display modes: PC: VGA, SVGA, XGA, SXGA, UXGA & WUXGA display modes HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p Product: Overall Length: 9.65" +/- 0.6" (245mm +/- 15mm) Weight: 0.09 lbs Color: Black Material: Plastic Connector: 20-Pin DisplayPort (male) to 15-pin VGA (female) DisplayPort connector housing (L x W x H): 1.93" x 0.78" x 0.51" (49 x 20 x 13 mm) VGA connector housing (L x W x H): 1.77" x 1.77" x 0.59" (45 x 45 x 15 mm) Environmental conditions: Operating temperature: 32 to 140 degrees F Storage temperature: 14 to 158 degrees F Humidity: < 85% non-condensing Certifications/ Standards: FCC, CE, RoHS Warranty: 3 years limit...
• Model #: CB-DP0N11-S1

• Type: DP to VGA
• Color: Black
• Cable Length: 9.0" +/- 0.5" (230mm +/- 13mm)
• Specifications: RoHS compliant
• Model #: CB-DP0082-S1

• Color: Black
• Connector A: 1x 19-Pin, HDMI, Type A, Female, Input
• Connector B: 4x 19-pin, HDMI, Type A, Female, Output
• Audio: DTS-HD Master Audio, Dolby TrueHD Dolby Digital, DTS, DVD-Audio, LPCM, SACD, MPCM
• Model #: CE-H22Y11-S1

• Type: DP to HDMI
• Color: Black
• Specifications: Chipset: PTN3361B Compliant with DisplayPort 1.1a receiver Compliant with HDMI specification, supporting up to 2.25 Gbps Configurable 1 or 2 lane operation Supports Down Spread Spectrum (SSC) Display modes: PC: VGA, SVGA, XGA, SXGA & UXGA display modes HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p Product: Overall Length: 9.65" +/- 0.6" (245mm +/- 15mm) Weight: 0.09 lbs Color: Black Material: Plastic Connector: Connectors: 20-Pin DisplayPort (male) to 24-pin DVI-D (female) DisplayPort connector housing (L x W x H): 1.93" x 0.78" x 0.51" (49 x 20 x 13 mm) DVI-D connector housing (L x W x H): 1.77" x 1.77" x 0.59" (45 x 45 x 15 mm) Environmental conditions: Operating temperature: 32 to 140 degrees F Storage temperature: 14 to 158 degrees F Humidity: < 85% non-condensing Certifications/ Standards: F...
• Model #: CB-DP0Q11-S1

• Type: Mini DP to VGA
• Color: White
• Specifications: Chipset: Analogix ANX9832 Compliant with DisplayPort 1.1a receiver Configurable 1 or 2 lane operation Supports 1.62 and 2.7 Gbps data rates Supports Down Spread Spectrum (SSC) Display modes: PC: VGA, SVGA, XGA, SXGA, UXGA & WUXGA display modes HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p Product: Overall Length: 8.85" +/- 0.6" (225mm +/- 15mm) Weight: 0.08 lbs Color: White Material: Plastic Connectors: 20-Pin Mini DisplayPort (male) to 15-pin VGA (female) Mini DisplayPort connector housing (L x W x H): 1.06" x 0.43" x 0.35" (27 x 11 x 9 mm) VGA connector housing (L x W x H): 1.77" x 1.77" x 0.59" (45 x 45 x 15 mm) Environmental conditions: Operating temperature: 32 to 140 degrees F Storage temperature: 14 to 158 degrees F Humidity: < 85% non-condensing Certifications/ Standards: FCC, CE, RoHS...
• Model #: CB-DP0R11-S1

• Type: Mini DP to VGA / HDMI / DVI
• Color: Black
• Specifications: Chipset: ANX9833 + PS8339 Version: Mini DisplayPort v1.2 Resolution: HDMI: Up to 4Kx2K @ 30Hz DVI: Up to 1920x1080 @ 60Hz, DVI-D (Single link) VGA: Up to 2048x1152 @ 60Hz Audio: HDMI: Up to 7.1 channel audio output DVI & VGA: No audio output
• Connector A: 1x 20-pin, Mini DisplayPort, Male, Input
• Model #: LB-CD0014-S1

OUT OF STOCK

• Type: DP to DVI
• Color: Black
• Specifications: Chipset: PTN3361B Compliant with DisplayPort 1.1a receiver Compliant with DVI 1.1 specification Configurable 1 or 2 lane operation Supports Down Spread Spectrum (SSC) Display modes: PC: VGA, SVGA, XGA, SXGA & UXGA display modes HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p Product: Overall Length: 9.65" +/- 0.6" (245mm +/- 15mm) Weight: 0.09 lbs Color: Black Material: Plastic Connector: Connectors: 20-Pin DisplayPort (male) to 24-pin DVI-D (female) DisplayPort connector housing (L x W x H): 1.93" x 0.78" x 0.51" (49 x 20 x 13 mm) DVI-D connector housing (L x W x H): 1.77" x 1.77" x 0.59" (45 x 45 x 15 mm) Environmental conditions: Operating temperature: 32 to 140 degrees F Storage temperature: 14 to 158 degrees F Humidity: < 85% non-condensing Certifications/ Standards: FCC, CE, RoHS Warranty: 3 ...
• Model #: CB-DP0P11-S1
