Specification: Screen
Size: 10.1" (256.54 mm) diagonal
IPS (In-Plane Switching)
LCD Panel with LED Backlighting
Resolution: 1280 x 800 resolution
Touch: Capacitive, 10 points multi-touch
Brightness: 400 nits
Contrast: 1000:1
Anti Fingerprint: Oleophobic coating
Viewing angle: 85 degrees (U/D/L/R)
Position angle: 0 degrees (flat on mounting surface)
General
Integrated accelerometer
Integrated ambient light sensor
100 mm x 100 mm VESA FDMI
Cable exits: horizontal / vertical / center
Compatibility and Certifications
Logitech Tap Scheduler integrates with leading room scheduling solutions as a
Microsoft Teams Panel
Zoom Rooms Scheduling Display
Robin-Powered scheduling panel
Meetio scheduling panel
Package Contents
Logitech Tap Scheduler (White)
Multi-surface mount (glass/drywall)
Corner mount accessory
Mullion mount
Mounting hardware
Documentation
Digital Video Capture Resolution: Graphics Modes (Live): 4K UHD
Maximum Video Resolution (Live): 3840 x 2160
Maximum Frame Rate: 60 fps
Specification: Interfaces/Ports
HDMI In
HDMI Out
Network (RJ-45)
USB
Number of Network (RJ-45) Ports: 1
Number of HDMI Inputs: 1
Number of HDMI Outputs: 2
Technical Information
Features: Noise Reduction
Room Size: Medium
Additional Features: Sleek and simple, the Control Plus Dual Mode Antimicrobial Presenter with Laser offers a simplistic button layout and integrated laser pointer, making it easy to give presentations. Connect the presenter via a USB receiver or Bluetooth and control your presentation up to 20 meters away. The USB receiver supports AES 128-bit encryption and seamlessly stores within the presenter. It even features a light indicator when the USB receiver is detached from the presenter, reducing the risk of leaving it behind.
Both stylish and functional, the Control Plus Dual Mode Antimicrobial Presenter with Laser is also ergonomic and features antimicrobial properties that help prevent bacteria growth on the presenter itself. The presenter comes equipped with one AAA battery and has an LED low battery alert when it's time to change the ...
Additional Features: Echo Cancellation
Tail time: 60 ms x 3
Noise Cancellation
Dynamic noise cancellation
Keypad
Alphanumeric standard keypad
Loudspeaker
Volume: 90dBspl A weighted @ 1 ft
Bandwidth: 200 Hz–3.3 kHz
Record Output
Connector: 2.5 mm mono audio jack
Impedance: <1000 ohms
Bandwidth: 200 Hz–3.3 kHz
Dynamic range: 60 dB
THD <.01%
Certifications
FCC part 15 Class A
FCC part 68
UL Certified
Environmental
Operating temperature: 32–118° F (0–48° C)
Storage temperature: 41–158° F (5–70° C)
Operating humidity: 15 to 80%
Storage humidity: 10 to 90%
Speakerphone: Yes
Power: Base unit:
Auto-adjusting power module;
100-240 VAC; 50/60 Hz
Connections: Analog PBX or PSTN line
RJ-11C, -12 dBm nominal
Additional Features: Front of Room Audio
With Rally Speakers at the front of the room, voices and video always come from the same direction — and never from behind you, a problem with tabletop speakerphones. With Rally Mic Pods on the table and Rally Speakers at the display, conversations feel natural and lifelike.
Anti-Vibration Enclosure
An ingenious suspension system decouples the speaker module within the external enclosure, virtually eliminating the vibrations that can travel through walls, stands, and tables. This patent-pending design enables the superior echo cancelling performance of Rally Mic Pods, while ensuring that video images remain clear and steady, even at high volume levels and when zoomed in.
Comfortable Volume in Larger Rooms
Turn up the clarity while keeping volume at a comfortable level for everyone in the room. With sound coming from two speakers r...
Camera: Maximum pixels: 2*48MP pixels
Number of preset positions: 9
Electronic gimbal
120° DFOV, 54° VFOV, 110° HFOV
Depth of field: 1-5 meters
6x digital zoom
Maximum resolution: 4K
Maximum frame rate: 60FPS
Video output resolution: 4K60fps, 1080P60fps
Effective focal length: 4.2 mm
Aperture: F/2.2-F/2.4
Supports wide dynamic range
High dynamic range imaging: 10-bit
Supports auto exposure
White balance: ATW/auto/manual
Shutter speed: 10ms-33ms
Minimum illumination: 0.5 lux (daytime), 0.1 lux (nighttime)
Signal-to-noise ratio: >63 dB
Privacy cover: Electric lens cap
Lens calibration
Intelligence Features
- IntelliFocus
- Auto Framing
- Speaker Tracking
People counting
- Picture in Picture
- Multi-focus Framing
- Smart Gallery (Zoom only)
Number of cameras: 2
Specification: Device Type: Meeting Bar
Room Size: Small to Medium
Attendee...
Additional Features: With a single USB connection, Logitech Swytch links a laptop to the room’s display, camera, and audio devices. Now, people can use meeting rooms with any video conferencing software, webinar platform, or streaming service.
Specification: SYSTEM REQUIREMENTS
- Meeting Room Equipment
Display: HDMI input
Conference Camera: USB conference camera with speakerphone
- Laptop Computers
USB 3.0 Port: Type A or Type C
USB Power Delivery: Up to 60 watts for compatible laptops that charge via USB Type C
Operating Systems with DisplayLink Plug and Display Drivers: Windows 10, macOS 10.15 and later, and Chrome OS 75 or later.
INSIDE THE BOX
Swytch Hub
Swytch Extender
Swytch Connector with 1.5m / 4.9ft USB Cable
100-240v Swytch Hub Power Supply
100-240v Swytch Extender Power Supply
5m / 16.4ft USB 3.0 Cabl...
Camera: Ultra-HD imaging system supports:
4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
1080p, 720p at 30fps and 60 fps
Additional Features: Studio-Quality Video
With an Ultra-HD imaging system, Rally delivers brilliantly sharp video, outstanding color, and exceptional optical accuracy at resolutions up to 4K. Logitech RightLight technology optimizes light balance to emphasize faces and render natural-looking skin tones, even in dim or backlit conditions.
Advanced Modular Audio
Crystal-clear audio is essential for world-class video
Specification: Supported Network Protocols
DHCP VLAN discovery; LLDP-MED for VLAN discovery; FTP/TFTP/HTTP/HTTPS server-based central provisioning; Manual or dynamic host configuration protocol (DHCP) network setup; QoS Support — IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS, and DHCP; Time and date synchronization using SNTP; Provisioning and call server redundancy support
Security Management
802.1X Authentication and EAPOL Media encryption via SRTP; Digest authentication; Encrypted configuration files; HTTPS secure provisioning; Password login; Support for signed software executables; Support for URL syntax with password; Transport Layer Security (TLS); Wi-Fi encryption: WEP, WPA-Personal, WPA2-Personal, WPA2-Enterprise with 802.1X (EAP-TLS, PEAP-MSCHAPv2); FIPS 140-2 compliant cryptographic module
Ports
1 USB 2.0 Type-A (for USB ...
