Features: • Industrial power supply with integrated DIN-rail mount
• Provides up to 240 Watts of power (48 V, 5 A)
• Built-in active PFC (PF > 0.93)
• Short circuit/overload/over voltage/over temperature protection
• High efficiency (94%) design
• UL 508 approved
• 100 % full load burn-in test
• Extreme -25 to 70 °C (-13 to
Specifications: Interfaces:
PoE IN:1 x 10/100/1000BASE-T Ethernet with IEEE 802.3at PoE "Data + DC power" in auto MDI/MDI-X, auto-negotiation RJ45 connector
PoE OUT: 2 x 10/100/1000BASE-T Ethernet with IEEE 802.3at/802.3af PoE "Data + DC power" out auto MDI/MDI-X, auto-negotiation RJ45 connector
Power over Ethernet
PoE Standard:
"PoE In" Port: IEEE 802.3at Power over Ethernet Plus end-span/mid-span PD class 4 PD
Per "PoE Out" Port:
IEEE 802.3at Power over Ethernet Plus end-span PSE
IEEE 802.3af Power over Ethernet end-span PSE
PoE Power Supply Type: End-span (Type A)
PoE Power:
"PoE In" Port: 52 - 56V DC, max. 30.8 watts
Per "PoE Out" Port: 44 - 55V DC, max. 25 watts
Power Pin Assignment:
"PoE In" Port: 1/2 (+), 3/6 (-); 4/5 (+), 7/8 (-)
Per "PoE Out" Port: 1/2 (+), 3/6 (-)
Data Rate: 10/100/1000Mbps
MAC Address Table: 2K
Data Bu...
Specifications: Interfaces/Ports: 1 x RJ-45
Data Transfer Rate: 230 Kbps Serial
Management: SNMP
Protocols:
Telnet
Reverse Telnet
PPP
SSH v2
HTTP
DHCP
ARP
RARP
TCP
UDP
Status Indicators: Link / Power
Input Voltage:
100 V AC to 240 V AC
9 V DC to 30 V DC
Input Current:
400 mA 12 V DC
500 mA 9 V DC to30 V DC
Specifications: Dimensions: 3.80" x 1.20" x 0.90"
Output Interface:
3 x USB-A 3.0 Ports
1 x Gigabit Ethernet Port
Input Interface: 1 x USB-A 3.0 Connector
Chipset: RTL8153
Supported Systems: Windows (XP / Vista / 7 / 8 / 8.1 / 10), Mac OS X (10.5-10.11), Linux OS and Chrome OS
Package Contents:
USB 3.0 3-Port Hub & Gigabit Ethernet Adapter UE330
User Guide
Interface: 1 x Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication§
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Specifications: Networking Interface:
PoE In (802.3af): 1 x Gigabit RJ45 Port
PoE Out (24V Passive): 1 x Gigabit RJ45 Port
Operating Temperature: 0 to 70 degree C (32 to 158 degree F)
Power Input: 48V, 802.3af
Max. Power Output: 24V, 0.5A
Power Method:
24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Wireless Data Rates: 802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) : up to 500 Mbps
WiFi 5 (802.11ac) (1024QAM) : up to 2167 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps
WiFi 6E (802.11ax) (6GHz) : up to 2402 Mbps
