Quick View
TP-Link PoE Splitter 802.3af Compliant Gigabit Port 5/9/12V DC Power Output Up to 100 meters325 feet TL-PoE10R, BlackType: PoE SplitterColor: BlackSpecifications: Interface:
2 x 10/100/1000Mbps RJ45 Port
AUTO Negotiation/AUTO MDI/MDIX
1 x POWER OUTPUT PORT
Network Media
10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100O STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100O STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Power Supply: 12VDC 1A, 9VDC 1A, 5VDC 2A
Basic Function:
Compatible With IEEE 802.3af Compliant PSEs
Delivers Power Up To 100 Meters
Optional 12VDC, 9VDC or 5VDC Power Output
LED Indicator: PWR
Dimensions: 3.2" x 2.0" x 0.9"
Certification: FCC, CE, RoHS
System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux.
Environment
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -40°C - 70°C (-40°F - 158°F)
Opera...Model #: TL-POE10R
Quick View
StarTech.com 1.2m 10G SFP+ to SFP+ Direct Attach CablePart Number: JD096CSTType: Network CableSpecifications: Type: 10GBase direct attach cable - SFF-8431/ SFF-8432
Technology: Twinaxial
Features: Passive cable
Length: 4 ft
Connector: SFP+ - latched
Connector (Second End): SFP+ - latched
Color: Black
OEM Manufacturer Equivalent Part Number: HP JD096C
Manufacturer Warranty: 2-year warranty
General
Network Cable Type: 10GBase direct attach cable - SFF-8431/ SFF-8432
Technology: Twinaxial
Jacket Material: PVC
American Wire Gauge (AWG): 30
Impedance: 100 Ohm
Features: Passive cable
Length: 4 ft
Weight: 2.65 oz
Color: Black
Connectivity
Connector: SFP+ - latched
Connector (Second End): SFP+ - latched
Miscellaneous
OEM Manufacturer Equivalent Part Number: HP JD096C
Compliant Standards: MSA, RoHS, FCCModel #: JD096CST
Quick View
Ubiquiti - Device Bridge Pro (UDB-Pro)Wireless Data Rates: Max Data Rates: 5 GHz: 867 Mbps (BW80)Frequency Band: US/CA:
U-NII-1 5150 - 5250 MHz
U-NII-2A 5250 - 5350 MHz
U-NII-2C 5470 - 5725 MHz
U-NII-3 5725 - 5850 MHzInterface: (2) GbE RJ45 portsBrand: Ubiquiti NetworksModel #: UDB-PRO
Quick View
Ubiquiti 15V 12W PoE AdapterType: PoE AdapterColor: BlackSpecifications: Output Voltage: 15V DC @ 0.8A
Rated Voltage: 100-240V AC @ 50/60 Hz
Input Current: 0.3A @ 120VAC,0.2A @ 240VAC
Inrush Current: <30A Peak @ 120V AC, <60A Peak @ 230V AC
Efficiency: 75+%
Output Ripple: 1% Max.
Switching Frequency: 50 kHz
Operating Temperature: 0 to 40 degree C (32 to 104 degree F)
Storage Temperature: 30 toFeatures: Provides Earth Grounding and Surge Protection
Helps Protect Against ESD Events
Powers Ubiquiti PoE DevicesModel #: POE-15-12W
Quick View
Ubiquiti Networks Wave Long-Range (Wave-LR)Frequency Band: RF
Operating frequency* 57–71 GHz
*Depends on regulatory region.
Channel bandwidth 2160, 1080, 540* MHz
*FW version 3.3.0 and later.
Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
*Depends on regulatory region.
Modulation 16QAM, QPSK
Antenna gain 46 dBi
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 1°
Elevation: 3 dB 1°
Back-Up RF
WiFi standard 802.11ax (WiFi 6)
Operating frequency*
US/ CA
Worldwide
U-NII-1 5150 - 5250 MHz
U-NII-2A 5250 - 5350 MHz
U-NII-2C 5470 - 5725 MHz
U-NII-3 5725 - 5850 MHz
5150 - 5875 MHz
*Depends on regulatory region.
Channel bandwidth 20, 40, 80 MHz
Modulation BPSK (1/2), QPSK (1/2), QPSK (3/4), 16QAM (1/2), 16QAM (3/4), 64QAM (2/3), 64QAM (3/4), 64QAM (5/6), 256QAM (3/4), 256QAM (5/6), 1024QAM (3/4), 1024QAM (5/6)
Antenna gain 2...Model #: WAVE-LR-US ₪1,613 .42 – ₪470.55 Shipping
Quick View
Planet LRP-101C-KIT 1-Port Long Reach PoE Over Coax Extender Kit (LRP-101CH + LRP-101CE)Type: PoE ExtenderColor: BlackSpecifications: Ethernet Interface: LRP-101CH
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI/MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both Mid-span and End-span PSE Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LRP-101CE
Copper: 10/100BASE-TX RJ45, Auto-negotiation / auto-MDI/MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
LRP-101CH
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACT
LRP-101CE
4 x LEDs
PWR
LRP LNK
PoE-in-us...Model #: LRP-101C-KIT ₪1,308 .05 – ₪174.18 Shipping
Quick View
Ubiquiti Networks INS-3AF-I-G Instant 802.3af Indoor ConvertersType: PoE ConverterColor: BlackSpecifications: Networking Interface:
PoE In (802.3af): 1 x Gigabit RJ45 Port
PoE Out (24V Passive): 1 x Gigabit RJ45 Port
Operating Temperature: 0 to 70 degree C (32 to 158 degree F)
Power Input: 48V, 802.3af
Max. Power Output: 24V, 0.5A
Power Method:
24V Passive PoE (Pairs 4, 5+; 7, 8 Return)Model #: INS-3AF-I-G
Quick View
Ubiquiti Networks Wave AP Micro (Wave-AP-Micro)WiFi Generation: Wi-Fi 6Frequency Band: RF
Operating frequency* 57–71 GHz
*Depends on regulatory region.
Channel bandwidth 2160, 1080, 540* MHz
*FW version 3.3.0 and later.
Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
*Depends on regulatory region.
Modulation 16QAM, QPSK
Antenna gain 20 dBi
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 90°
Elevation: 3 dB 7°
Electrical downtilt 0°
Back-Up RF
WiFi standard 802.11ax (WiFi 6)
Operating frequency*
US/ CA
Worldwide
U-NII-1 5150 - 5250 MHz
U-NII-2A 5250 - 5350 MHz
U-NII-2C 5470 - 5725 MHz
U-NII-3 5725 - 5850 MHz
5150 - 5875 MHz
*Depends on regulatory region.
Channel bandwidth 20, 40, 80 MHz
Modulation BPSK (1/2), QPSK (1/2), QPSK (3/4), 16QAM (1/2), 16QAM (3/4), 64QAM (2/3), 64QAM (3/4), 64QAM (5/6), 256QAM (3/4), 2...Model #: WAVE-AP-MICRO-US ₪2,107 .16 – ₪274.69 Shipping
Quick View
Lantronix XDT10P0IA-01-S xDirect-IAP PoEType: Device ServerSpecifications: xDirect PoE Single Port RS232/422/485 10/100 Device Server, No Power Supply, RoHS
Memory: 256 KB Standard; 1 MB Flash
Data Link Protocol: Ethernet, Fast Ethernet, RS-232, ASCII, RS-422, RS-485, Modbus
Certifications & Standards Emissions:
FCC Part 15, Subpart B, Class B
EN55022, Class B
EN61000-3-2, EN61000-3-3
ICES-003 Issue 4
AS/NZS CISPR22
Immunity:
EN55024
EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5,
EN61000-4-6, EN61000-4-8, EN61000-4-11
Agency Approvals:
UL 60950-1, 2nd Edition
CAN/CSA C22.2 No. 60950-1-07, 2nd Edition
CE
VCCI
C-Tick
IEC 60950-1 2005, 2nd Edition
Input Voltage: 120 V AC, 230 V ACModel #: XDT10P0IA-01-S
Quick View
Panorama BSM-6-60-05NJ 4G/5G MIMO OMNI TUBE ANTENNA 0.5 m N (f)Type: AntennaColor: GreySpecifications: MIMO Type: 2x2 MIMO
Antenna Connectors: N-Type Female
Frequency Range: 617-960 / 1427-6000 MHz
Antenna Gain: 617-960MHz: 3dBi, 1427-2700 MHz: 6dBi, 3400-4200MHz: 5dBi, 4.9-6000Mhz: 5dBi
Impedance: 50 Ohms
Max Input Power: 10 W
Dimension: 21.25" x 3.38" x 3.38"Model #: BSM-6-60-05NJ ₪724 .22 – ₪223.36 Shipping
Quick View
Brainboxes ED-588 Ethernet to Digital IO 8 Inputs + 8 OutputsType: N/ASpecifications: Description: 8 Digital Inputs and 8 Digital Outputs
Digital Inputs: 8
Logic Level 0: -30.0V to +1.0V
Logic Level 1: +2.0V to +30V
Latched Inputs: Triggered by user programmable positive or negative edges, stays true until acknowledged
Counter Inputs: User progammable- counts positive or negative transitions up to 100Hz
Watchdog: Active high/low, Pulsed high/low
Digital Outputs: 8
Digital Output Type: Open drain transistor, protected MosFET. Short circuit protection up to 36V. Over temperature shutdown -175°C typical 150°C min
Maximum Output Load Voltage: 30 VDC
Maximum Output Current Sink: 0.85A per channel
Serial Gateway: RS485 NuDam/ADAM compatible gateway
Number of Ports: 1
Network Port Type: RJ45 Jack 10/100 MHz Autosensing, Cross Over Autosensing (MDIX)
Network Protocols: ICMP, IP, TCP, DHCP, HTTP
Protection: 1500V M...Model #: ED-588 ₪1,109 .15 – ₪122.68 Shipping
Quick View
Ubiquiti Networks - Wave Pico (Wave-Pico)Frequency Band: RF
Operating frequency* 57–71 GHz
*Depends on regulatory region.
Channel bandwidth 2160, 1080, 540* MHz
*FW version 3.3.0 and later.
Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
*Depends on regulatory region.
Modulation 16QAM, QPSK
Antenna gain 27.7 dBi
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 6°
Elevation: 3 dB 6°
Back-Up RF
WiFi standard 802.11ax (WiFi 6)
Operating frequency*
US/ CA
Worldwide
U-NII-1 5150 - 5250 MHz
U-NII-2A 5250 - 5350 MHz
U-NII-2C 5470 - 5725 MHz
U-NII-3 5725 - 5850 MHz
5180 - 5875 MHz
*Depends on regulatory region.
Channel bandwidth 20, 40, 80 MHz
Modulation BPSK (1/2), QPSK (1/2), QPSK (3/4), 16QAM (1/2), 16QAM (3/4), 64QAM (2/3), 64QAM (3/4), 64QAM (5/6), 256QAM (3/4), 256QAM (5/6), 1024QAM (3/4), 1024QAM (5/6)
Antenna gain 9 d...Model #: Wave-Pico
