Specifications: Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB 3.1 USB Type-A (9 pin; Gen 2; 10 Gbps) Male
Bus Type: USB 3.1 Gen 2
Chipset ID: ASMedia - ASM1351
Compatible Drive Types (Type and Rate): SATA
Drive Size: 2.5in
Interface: USB 3.1 Gen 2
Number of 2.5 inch bays: 1
Number of Drives: 1
Hot Swap Capability: Yes
Max Drive Capacity: Currently tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate : 10 Gbps
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s
UASP Support: Yes
Specifications: The USB-C to Ethernet Adapter is an ideal solution for wired network connectivity and data transfer on the go, in the office, or any work space. This adapter connects to a USB-C or Thunderbolt 3 enabled laptop, tablet, or desktop computer and features an Ethernet port.
The small form factor of this adapter makes it a portable and convenient solution that provides a Gigabit Ethernet port for a wired internet connection. The adapter is perfect for connecting to networks where Wi-Fi is unavailable or for computers that do not provide a wired Ethernet port or possibly have a damaged Ethernet port.
The Ethernet port allows for reliable internet connectivity and file transfer speeds up to 1000Mbps.
Specifications: USB 2.0 Full-speed (480Mbps) specification USB HID class specification 1.1 USB Audio device class specification 1.0 USB Type A, stereo output jack, mono microphone input jack connectors Supports: Windows 98se /ME / 2000 / XP / Server 2003 / Vista/Windows 7 and Windows 8 Linux/ MacOS 10/ System Requirement : Desktop or notebook PC with a USB port, Stereo active speakers or stereo earphone
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
LED Indicators: 1 x IDE; 1 x SATA; 1 x USB; 1 x Power
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: Humidity: 0~65% RH
Operating Temperature: 0 to 60 degree C
Storage Temperature: -20 to 80 degree C
FIFO: 512 Bytes
Flow Control: None, Xon/Xoff, RTS/CTS, DTR/DSR
Max Baud Rate:921.6 Kbps
MTBF:30,000 Hours
OS Compatibility:
Windows 7, 8.1, 10
Windows Server 2008 R2, 2012 R2, 2016
Mac OS X 10.11 and 10.12
Linux 2.6.x to 4.4.x LTS Versions only
Specifications: Bus Type: USB 2.0
Chipset ID: FTDI - FT232RL
Interface : Serial
Port Style: External Hub
Ports: 16
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators 16 - Data Receive
16 - Data Transmit
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: N
Power Consumption: 36 W Max.
Power Source: AC Adapter Included
Humidity: 20~80% RH (Non-condensing)
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Storage Temperature: -65°C to 150°C (-85°F to 302°F)
Enclosure Type: Steel
Specifications: Bus Type: PCI Express Mounting Type: Full Profile PCI slot cover Chipset: VIA VL805 Interface: 2x USB 3.0 Port Type-A & Internal USB 20pin header Data Transfer Rate: USB 3.0 - 5 Gbit/s Connector Type (s) 1 - PCI Express x1 Male External Ports: 2x USB 3.0 Port Type-A Female Internal Ports 2 - USB 3.0 20pin male Power Supply: Build in Self-Powered Technology,Owns individual 2A power supply,no additional power input is required. Supports motherboard PCI-E X1 X4 X8 X16 slot Compatible OS: Compatible with 64-bit and 32-bit Windows 10 / 8.1 / 8/7 / XP.
Package Contents: 1 x PCIe USB 3.0 PCI express card,1 x Low Profile PCI Slot Cover
Specifications: Material of Construction: PC (Plastic)
Cable Jacket Rating: VW-1
Cable Outer Diameter (OD): 3.9mm
Wire Gauge (AWG): 32 + 28
Side A - Connector 1: USB A (MALE)
Side A - Connector 2: USB C (MALE)
Side B - Connector 1: RJ45 (FEMALE)
USB Specification: USB 1.1 (up to 12 Mbps); USB 2.0 (up to 480 Mbps); USB 3.0 (up to 5 Gbps)
Driver Required: No
Recommended Category Cable: Cat6/6a
Remote Wakeup Support: Yes
Network Speed Support: 1 Gbps (Gigabit)
Specifications: System Requirements:
1 or 2 computers with available USB ports
Switch is compatible with all USB-enabled operating systems
Optional software is compatible with Windows (XP and later) and Mac (OS X 10.3 and later)
Approvals: FCC and CE
Specifications: Wired network connection
Supporting laptops without Ethernet ports, the Kensington CA1100E USB-C to Gigabit Ethernet Adapter provides a direct and secure connection to your internet or LAN. Connecting the USB-C (male) connector to your device’s USB-C or Thunderbolt 3 port, and the Ethernet cable to the RJ45 (female) port, will provide a secure hard-wired connection.
Gigabit transfer speeds
Increase your productivity and peace of mind with 10/100/1000 BASE-T performance. Securely transfer and download even the largest of files with the confidence that only a wired connection can provide.
Plug and Play Design
Simply plug the adapter into the USB-C or Thunderbolt 3 port on your laptop and connect to your network. Compatible with Windows 8...
Specifications: Connector on First End:1 x Type A Male USB 3.0 USB
Connector on Second End:1 x 40-pin IDC Female IDE
1 x 7-pin Male Serial ATA 3.0 SATA
Package Contents: USB 3.0 to SATA / IDE Combo Adapter
USB 3.0 Cable - 2.5 ft.
4-Pin Molex Power Cable
External Power Supply (Input: 100-240V, 50/60Hz, 0.8A Output: 12V, 2A)
Owner's Manual
Backup Software CD
