Intel NUC 13th gen Core i7-13700K Z690 Raptor Canyon RNUC13RNGI70001 supports DDR5 SODIMM , Thunderbolt 4, PCIe x16 Gen5 3-slot wide GPU, Intel® Killer(tm) Wi-Fi 6E AX1690 (i/s)
- Intel® Core™ i7 -13700K
- Intel® UHD Graphics 770
- Dual channel DDR5-4800 SODIMMs, max 64GB (Memory not included)
- 1x M.2 22×80 for NVMe
- 2x M.2 22×80 for NVMe or SATA SSD
- Intel® Killer Wi-Fi 6E AX1690i w/ 6GHz + Bluetooth® v5.2
- Auxiliary Extension x4
- 4 addressable RGB headers
- 2x 120mm System Fans
- 2x USB 3.2 Gen 1 Type-A (top)
- 1x USB 3.2 Gen2x2 Type-C (top)
- 1x 3.5mm stereo headphone jack (top)
- 2x external antennas
- 6x rear USB 3.2 Gen 2 ports
- 10 Gb Ethernet (AQC113) port
- Intel® 2.5 Gb Ethernet (i226-V) port
- 2x Thunderbolt 4 / USB4 Type-C ports
- 750W 80+ Gold SFX 12VO internal power supply
- 1x HDMI 2.1 TMDS compatible connector (up to 4k60)
- Analog audio
- Triple slot PCIe X16 Gen5 socket (GPU not included)
- Kensington lock
Specs
Reviews (10)
Learn more about the Intel RNUC13RNGi70001
| Brand | Intel |
|---|---|
| Series | NUC 13 |
| Model | RNUC13RNGi70001 |
| Part Number | RNUC13RNGi70001 |
|---|
| Color | Black |
|---|
| CPU Installed | Intel® Core™ i7 -13700K | 8P+8E/24T | P-Cores: up to 5.4 GHz - E-Cores: up to 4.2 GHz | 30MB Intel® Smart Cache | 125W Unlocked TDP |
|---|
| Memory installed | No Memory |
|---|---|
| Memory slot | Dual channel DDR5-4800 SODIMMs, max 64GB |
| Max Memory Supported | 64GB |
| Dual Channel Memory Supported | Yes |
| M.2 | 1x M.2 22x80 M-Key x4 PCIe supporting NVMe Gen4 (512GB to 4TB), Gen3 (128GB to 8TB) 2x M.2 22x80 M-Key x4 PCIe supporting NVMe Gen4 (512GB to 4TB), Gen3(128GB to 8TB) and SATA SSD (128GB to 2TB) |
|---|
| Discrete Graphic Card | Triple-slot GPU capable | Max Length: 313mm | Max Slot Thickness: 63mm | Max Card Height:155mm | Max Backplate Thickness: 3.5mm |
|---|---|
| Onboard Video | Intel® UHD Graphics 770 up to 1.60 GHz | |
| Onboard Audio | 3.5mm front stereo headset jack |
|---|
| First LAN | 1x 10Gb Marvell LAN (AQC113) |
|---|---|
| Second LAN | 1x 2.5Gb LAN (i225-LM) |
| Wireless LAN | Intel® Wi-Fi 6E AX1690i |
| Bluetooth | Bluetooth 5.2 |
| Front USB | 2x USB 3.2 Gen 1 Type-A (top) 1x USB 3.2 Gen2x2 Type-C (top) |
|---|---|
| Front Audio Ports | 1x 3.5mm stereo headphone jack (top) |
| HDMI | 1x HDMI 2.1 TMDS compatible connector (up to 4k60) |
|---|---|
| Thunderbolt 3 | 2x Thunderbolt 4 / USB4 Type-C ports |
| Rear USB | 6x rear USB 3.2 Gen 2 ports |
| RJ45 | 10 Gb Ethernet (AQC113) port Intel® 2.5 Gb Ethernet (i226-V) port |
| Rear Audio Ports | Analog audio with discrete Mic-in, Line-in, Speaker-out, FP audio Header |
| Input | 750W 80+ Gold SFX 12VO internal power supply |
|---|
| Dimensions | 337 x 318 x 129 mm (<14L volume) |
|---|
| Features | 2x external antennas 2x 120mm system fans 2x SATA ports | 2x 12V PWM Fan headers | USB 3.2 Gen 2 header | DC power for SATA HDDs | 4 addressable RGB headers supporting up to 120 LEDs |
|---|
| First Listed on Newegg | January 09, 2023 |
|---|
