Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
Genesys Logic - GL3523
Realtek - RTL8153
Eton Technology - EJ899T
Parade Technologies - PS176
ITE -IT6516
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Analog Resolutions: 1920 x 1200p @ 60Hz (VGA)
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p @ 30Hz (HDMI)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 to 10.14
Chrome OS
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
VIA/VLI - VL102
VIA/VLI - VL817
Parade - PS8338B
Parade - PS176
Analogix - ANX9833
ALCOR MICRO - AU84612
Realtek - RTL8153
Fast-Charge Port(s): Yes
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Audio Specifications: The HDMI port supports audio output
Compatible Networks: 10/100/1000 Mbps
Auto MDIX: Yes
Full Duplex Support: Yes
Maximum Resolutions:
1920 x 1200p @ 60Hz (VGA)
3840 x 2160p (HDMI) @ 30Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p
Maximum Data Transfer Rate : 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
UASP Support: Yes
Powe...
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI, VGA
Chipset ID: ITE - IT6222
Audio Specifications: HDMI output: 5.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz (VGA)
Maximum Digital Resolutions: 3840 x 2160 @ 30Hz (HDMI)
Supported Resolutions:
Maximum HDMI output:3840 x 2160 @ 30Hz
Maximum VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0
Specifications: Audio Specifications: HDMI output - 7.1 surround sound; DVI output - 2-channel stereo audio
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 × 2160
Maximum Power Delivery Support: None
Supported Resolutions: HDMI output: 3840 x 2160 (@ 30 Hz), 2560 x 1600, 2048 x 1280 (@ 60 Hz), 1920 x 1200, 1920 x 1080, 1280 x 720; VGA and DVI output: 1920 x 1200 (@ 60 Hz), 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Output Connector: 1 x HDMI (19 pin) Female Output
1 x DVI-I (29 pin) Female Output
1 x VGA (15 pin, High Density D-Sub) Female Output
Changer Type: USB Type-C to Type-A, VGA & Type-C Adapter
Color: White
Specifications: Connect A: USB 3.1 Type-C Male
Connect B: USB 3.0 Type-A Female / VGA (HD15) Female / Type-C Female
Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
Specifications: Easy to Add Displays:
Extend video to a second monitor, duplicate the same video on both monitors or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Add up to 6 adapters for a total of 7 displays (Windows)
Add up to 4 adapters for a total of 5 displays (Mac)
No need to reboot system after adding or removing a monitor
Plug and play - no external power supply needed
Vibrant, Superior Video Quality:
Supports high-definition video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Features 128 MB DDR SDRAM of memory
Resumes automatically from hibernation and suspend modes
Broad Compatibility:
Works with 32- and 64-bit Windows 2000 and later
Works with 32- and 64-bit Intel Mac OS...
Specifications: Connector A: USB C (MALE)
Connector B: HD15 (FEMALE)
Chromebook Compatible: Yes
System Requirements
Windows XP, Vista, 7, 8 or 8.1 or Mac OS X 10.8.3 and later (32- and 64-bit versions)
Computer with USB-C port and at least 1.2 GHz single-core CPU and 512 MB of RAM
HDMI-enabled monitor
Supports Surface tablets running non-RT Windows 8 or 8.1
Specifications: Compatible with Ubuntu 14.04.2
Connector A USB 3.0 A (MALE)
Connector B HD15 (FEMALE)
System Requirements
Compatible with Windows XP, Vista, 7, 8, and 8.1. Supports both 32- and 64-bit.
Supports Surface tablets running non-RT Windows 8 and 8.1
Compatible with Intel Mac OS X 10.8 (10.8.3 and later), 10.9 and 10.10 (Mac OS X 10.9 and 10.10 is limited to a single add-on monitor. See driver Release Notes for details) Supports both 32- and 64-bit.
Mac OS X versions 10.8.5 and earlier do not support audio over USB 3.0. Mac OS X versions 10.7.x and earlier do not support USB 3.0.
Reference the owner's manual for system requirements when using multiple adapters or when using the add-on monitor for DVD playback.
Specifications: USB 3.1 Type-C to VGA adapter for connecting a USB-C enabled smartphone, tablet or computer to an VGA-equipped monitor or display Compatible with analog VGA-enabled TVs/Monitors/Projectors for both video transfer This USB-C to VGA adapter Only Compatible with device with DisplayPort Alt Mode, Windows computers may need updated USB-C or Thunderbolt 3 drivers from the manufacturer. Video resolution up to 1920x1080p@60Hz for compatibility with most displays, monitors and projectors compatible with the following PC, Laptop: iMac 2017 / iMac Pro 2017 MacBook Pro 2017 & 2016 MacBook 2016 & 2015 New Chromebook Pixel Dell XPS 15 & 13 & 12 Yoga 920 Yoga 910, For Yoga 910 users, please ONLY plug the adapter into the White USB-C female port. Yoga 900(Yoga 4 Pro) HP Spectre x360 13 & 15 inch Asus Zen AIO All in One PC Surface Book 2 More Thunde...
Specifications: Supports USB DisplayPort Alternate Mode for Transmitting Video
Reversible USB-C plug connects your device to an existing VGA display, saving you the time, money and effort of additional adapters and cables
Extend video to a second monitor, duplicate the same video on both monitors, or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Plug and play with no external power supply or drivers required
Compatible with USB-C devices that support USB DisplayPort Alternate Mode
Vibrant, Superior Video Quality
Supports HD video resolutions up to 1920 x 1200 @ 60 Hz
Supports USB 3.1 Gen 1 data transfer rates up to 5 Gbps
Supports 36-bit Deep Color (12...
