Wenglor Photoelectronic Sensors HN55PA3 PNP New
- Wenglor Photoelectronic Sensors HN55PA3 PNP New
+
+
Overview
Specs
Reviews
Wenglor Photoelectronic Sensors HN55PA3 PNP New
Range 500 mm
Adjustable Range 70...500 mm
Switching Hysteresis < 5 %
Light Source Red Light
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Light Spot Diameter see Table 1
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) 30 mA
Switching Frequency 1 kHz
Response Time 500 µs
Temperature Drift < 5 %
Temperature Range -25...60 °C
Switching Output Voltage Drop < 2,5 V
PNP Switching Output/Switching Current 200 mA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Protection Class III
Setting Method Potentiometer
Housing Material Plastic
Degree of Protection IP67
Connection M12 × 1; 4-pin
PNP NO/NC antivalent yes
TTFd (EN ISO 13849-1) 2437,64 a
Range 500 mm
Adjustable Range 70...500 mm
Switching Hysteresis < 5 %
Light Source Red Light
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Light Spot Diameter see Table 1
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) 30 mA
Switching Frequency 1 kHz
Response Time 500 µs
Temperature Drift < 5 %
Temperature Range -25...60 °C
Switching Output Voltage Drop < 2,5 V
PNP Switching Output/Switching Current 200 mA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Protection Class III
Setting Method Potentiometer
Housing Material Plastic
Degree of Protection IP67
Connection M12 × 1; 4-pin
PNP NO/NC antivalent yes
TTFd (EN ISO 13849-1) 2437,64 a
