Wenglor Inductive Sensors I1BH004 PNP New
- Wenglor Inductive Sensors I1BH004 PNP New
+
+
Overview
Specs
Reviews
Wenglor Inductive Sensors I1BH004 PNP New
Switching Distance 2 mm
Correction Factors Stainless Steel V2A/CuZn/Al 1,16/0,70/0,67
Mounting flush
Mounting A/B/C/D in mm 0/9/6/0
Mounting B1 in mm 0...3
Switching Hysteresis < 10 %
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 10 mA
Switching Frequency 920 Hz
Temperature Drift < 10 %
Temperature Range -40...80 °C
Switching Output Voltage Drop < 1 V
Switching Output/Switching Current 150 mA
Residual Current Switching Output < 100 µA
Short Circuit Protection yes
Reverse Polarity and Overload Protection yes
Protection Class III
Housing Material Plastic
Degree of Protection IP67
Connection M8 × 1; 3-pin
MTTFd (EN ISO 13849-1) 3706,54 a
Error Indicator yes
PNP NC yes
Switching Distance 2 mm
Correction Factors Stainless Steel V2A/CuZn/Al 1,16/0,70/0,67
Mounting flush
Mounting A/B/C/D in mm 0/9/6/0
Mounting B1 in mm 0...3
Switching Hysteresis < 10 %
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 10 mA
Switching Frequency 920 Hz
Temperature Drift < 10 %
Temperature Range -40...80 °C
Switching Output Voltage Drop < 1 V
Switching Output/Switching Current 150 mA
Residual Current Switching Output < 100 µA
Short Circuit Protection yes
Reverse Polarity and Overload Protection yes
Protection Class III
Housing Material Plastic
Degree of Protection IP67
Connection M8 × 1; 3-pin
MTTFd (EN ISO 13849-1) 3706,54 a
Error Indicator yes
PNP NC yes
