2 x USB 3.0, 1 x USB 3.2 Type-C/ 1 x Audio, Front Ports
1 x 3.5" HDD or 2 x 2.5" SSD Internal 3.5" Drive Bays
+
+
Overview
Specs
Reviews (278)
Before you finalize your high-performance gaming rig, consider the Y40 S-Tier Aesthetic Panoramic Tempered Glass ATX Mid-Tower Gaming Computer Case in a striking red finish. This sleek and stylish case is the epitome of modern gaming aesthetics, offering an elegant and high-tech housing for your dream setup. The Y40 builds upon the innovative vertical graphics architecture of the Y60, enhancing performance, compatibility, and visual appeal. It comes equipped with a luxury PCIE 4.0 riser cable, ensuring support for the latest and most powerful graphics cards. The color-matched canopy, a signature feature introduced with the Y60, adds a touch of sophistication to your build.
Understanding the evolving demands of next-generation graphics cards, the Y40 expands GPU support to four full slots, providing additional airflow space between the card's edge and the glass. This design is complemented by an intake fan located beneath the power supply shroud, which channels fresh air upwards to the GPU, significantly improving cooling efficiency. The Y40's intelligent design allows for direct air injection into the GPU from a strategically placed fan below the expansion cards. Unlike typical vertical graphics orientations that limit expansion, the Y40 supports up to six half-height expansion cards behind the primary graphics card.
This ensures compatibility with a variety of components such as capture cards, PCIE SSDs, sound cards, and more, provided they are available in a half-height form factor. Cooling is a breeze with the Y40, which mirrors the airflow design of its older sibling, the Y60. The case includes two pre-installed 120mm fans - one beneath the floor and one at the rear. It accommodates a side-mounted liquid cooler, which can fit up to a 280mm radiator with a combined thickness of up to 120mm, perfect for custom loop configurations.
Additionally, the top mount can house up to a 360mm radiator for an impressive dual radiator setup. The Y40 also supports large air coolers over 180mm in height, making it compatible with nearly every CPU air cooler on the market. Cable management is a breeze with the Y40, featuring ample space behind the motherboard shelf and within the PSU shroud. The innovative cable "shelf" under the PSU shroud allows for neater cable organization, keeping them away from critical airflow zones that could impact GPU cooling. The Y40's assembly process is straightforward for those familiar with ATX cases.
It features a widened cable management viewport on the top of the case for easy access to CPU power or fan headers. The front glass is securely screwed to the top and bottom of the case but can be removed during assembly. The cable shelf around the PSU is perfect for securing excess cabling, and additional tie-down points on the back of the case cater to those who are meticulous about cable management. Thermal performance is paramount, and the Y40 benefits from the thermal testing insights gained from the Y60, featuring a similar airflow layout.
For optimal airflow, the side and bottom fans are configured as intake, while the top and rear fans serve as exhaust. When using liquid cooling for both GPU and CPU, the side fans' airflow direction can be adjusted for the best thermal performance. In comparison to the Y60, the Y40 showcases superior air-cooled GPU thermal performance, thanks to the increased clearance between the GPU fans and the side glass. This was demonstrated in tests using a 280mm side intake radiator with fans at 1000 rpm and three 120mm top exhaust fans also at 1000 rpm.
Elevate your gaming experience with the Y40 S-Tier Aesthetic Panoramic Tempered Glass ATX Mid-Tower Gaming Computer Case, where functionality meets elegance in a design that stands out in any gaming setup.
HYTE Y40 Modern Aesthetic Mid-Tower ATX Computer Gaming Case
The Next Evolution in PC Building
The HYTE Y40 computer chassis has a smooth, harmonic design with precisely beveled edges and 2-piece panoramic glass that showcases your unique PC build. With a focus on the future, the HYTE Y40 has a clean aesthetic and delivers upgraded performance capabilities and compatibility with future PC parts. The included PCIE 4.0 riser cable supports the latest and greatest graphics cards, while the Y40 boasts 4 full slots for GPU support and additional airflow space for high intensity processing. Build the perfect gaming desktop with the HYTE Y40’s ample space and high performance capabilities.
KEY FEATURES
Mid-Tower ATX PC Case
Designed for maximum desk appeal showcasing components
Bezel-less Panoramic Tempered Glass
Included PCIE Gen 4 riser for vertical graphics orientation
The case comes with 2x 120mm fans pre-installed, one beneath the floor and one at the rear.
Looks Cool, Runs Cooler
HYTE Y40's unique airflow path allows for a wide range of compatibility and plenty of cooling options.
Modern Aesthetic Design
Details connect every part into a deeply harmonic design structure. Every edge is adorned in tightly controlled beveling for s-tier aesthetics. 2-Piece Panoramic Glass set the stage for a completely unobstructed view of your system’s performance.
Cables, Managed
The cavity under the PSU shroud features HYTE's new cable "shelf" which allows cable management to sit further back within the case and away from airflow zones that may impact GPU cooling?.
Learn more about the HYTE CS-HYTE-Y40-BR
Model
Brand
HYTE
Series
Y40
Model
CS-HYTE-Y40-BR
Details
Type
ATX Mid Tower
Color
Black / Red
Case Material
ABS / Steel / Tempered Glass
Motherboard Compatibility
ATX / Micro ATX / Mini ITX
Side Panel Window
Yes
Dust Filters
Top Side Bottom x 2
Expansion
Internal 3.5" Drive Bays
1 x 3.5" HDD or 2 x 2.5" SSD
Expansion Slots
4 + 6 half-height
Front Panel Ports
Front Ports
2 x USB 3.0, 1 x USB 3.2 Type-C/ 1 x Audio,
Cooling System
Fan Options
Bottom - 1 x 120mm / Bottom - 1 x 140mm / Rear - 1 x 120mm / Side - 2 x 120mm / Side - 2 x 140mm / Top - 3 x 120mm
Radiator Options
Side: 120, 140, 240, 280mm up to 120mm thick Top: 120, 240, 360mm Rear: 120mm
Dimensions & Weight
Max GPU Length
422mm length, 94mm height (80mm height or less recommended for best cooling)
