Specifications: Required to mount mounting solutions and peripherals to the command post
Can be used with 200, 300, 400 Series and HD Pivot
Post is 3" by 3"
Specifications: Includes height-adjustment column, desk clamp, crossbar, two (2) LCD pivots, worksurface, large keyboard tray
NOTE: Extra-long cables may be required to span between standing and sitting heights
Worksurface Dimensions: 0.25"H x 23"W x 15"D (6 x 585 x 380 mm)
Keyboard Tray Dimensions: 0.25"H x 27"W x 9"D (6 x 685 x 226 mm)
Weight Capacity: Maximum total load on height-adjustment assembly = 25 lbs (11.4 kg). LCD weight = 6-12 lbs (2.7-5.5 kg) each, worksurface = 5 lbs (2.3 kg), keyboard tray = 5 lbs (2.3 kg). For proper operation the total weight of components when added together should not exceed 25 lbs (11.4 kg)
Lift Range: LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 4.8" (12.2 cm) independently; maximum LCD height adjustment = 22.8" (58 cm). The wor...
Type: SV Large Wire Basket for SV Carts and eTable
Specifications: Use Ergotron 98-135-216 large basket to store items on the Patient eTable and Styleview Carts. Easily attaches to the cart's t-slot channel.
Specifications: Weight Capacity: 23 lbs
LCD Size: 24"
Tilt: 180º
Pan: 180º
Rotation: 360º
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. To increase support, a separately-ordered Wall Plate or Wall Track accessory is recommended
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Shipping Weight: 3 lbs (1.4 kg)
Specifications: Includes height-adjustment column, desk clamp, LCD pivot, worksurface, large keyboard tray
NOTE: Extra-long cables may be required to span between standing and sitting heights
Weight Capacity: Maximum total load on height-adjustment assembly = 29 lbs (13.2 kg). LCD weight = 16-28 lbs (7.3-12.7 kg), worksurface = 5 lbs (2.3 kg), keyboard tray = 5 lbs (2.3 kg). For proper operation the total weight of components when added together should not exceed 29 lbs (13.2 kg)
Lift Range: LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 4.8" (12.2 cm) independently; maximum LCD height adjustment = 22.8" (58 cm). The worksurface restricts the vertical travel range of the LCD lift pivot; height adjustment of LCD without worksurface is 5" (13 cm)
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 ...
Specifications: Includes stand, CPU strap, buckle cover, VESA monitor mounting kit, cable ties
* Weight Capacity: 6 - 16 lbs. for display; total stand capacity = 37 lbs for combined weight of display, CPU, keyboard and mouse
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Meets tip test requirements of UL Specification 1678
Compatible with most 15" - 24" displays, and most small or ultra small form factor CPUs, notebook computers, and gaming consoles
Maximum CPU size = 14" H x 4" D (36 x 10 cm); minimum CPU size = 7" H x 1.8" D (18 x 4.6 cm). The CPU should be centered on the stand
Motion may be restricted when using 22" - 24" monitors in portrait mode
Removal of lock screw allows portrait to landscape rotation
Mounting Option: Two M4 threaded screw inserts are located at the bottom of ...
Specifications: LCD Size: <= 22"
Weight Capacity: 13 lbs (5.9 kg) per mount, 26 lbs (11.8 kg) total. Note: Monitors must be equal in weight or ±1 pound (.45 kg)
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Install display mounts on the bow at +2.5° or -2.5° angle to optimize viewing conditions
Monitors are installed with 8° inward off-set angle, creating a 16° viewing parabola for better sight lines
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Durable, easy-to-clean powder-coated painted steel exterior
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
Includes wall mount bracket, 2 extensions, crossbar and 2 sliding LCD mounts, VESA mounting screws
Specifications: Cable Manager: Cable Management Kit (grey).
Includes:
one (1) piece of 30" (76 cm) cable wrap, two (2) pieces of 11" (28 cm) cable management channel, two (2) adhesive strips, four (4), mounting screws, and four (4) hollow wall anchors.
Cable Channel Dimensions: 11.25" x 1.75" x 0.75" (286 x 44 x 19 mm)
