Question 1

can two of these units be connected to give 16 poe ports?

Accepted Answer

Two switches can be connected together vie ethernet cord.  This would not provide 16 ports.  Assuming one line coming in for internet, and one line going from switch one to switch two; you would have 6 available ports on switch one and 7 available ports on switch two.  Each port on the switch auto negotiates with the device plugged in to determine if it needs poe or just standard connection.

Question 2

Can you power this with PoE from another switch?

Accepted Answer

No, it is not designed for that.  It will require 120VAC, assuming USA geographical location.  More information is available in the PoE specifications on how that process works.

Question 3

What does" PoE Power Budget: 64W" mean.  Does that mean if I have 8 ports with cameras on each port,  I only have 8 w per port for power?

Accepted Answer

That is pretty much correct. I have a bunch of these switches in production for two years now and they each have five Polycom IP331 phones attached and they have been trouble-free.

Brand	D-Link
Model	DGS-1100-08P

Standards	IEEE 802.3/3u/3ab, IEEE 802.3af
Network Management Type	Smart

Primary Ports	8 x RJ45
Primary Port Speed	10/100/1000Mbps

MAC Address Table	8K
Switching Method	Store and Forward
VLAN Support	Yes
Buffer Memory	2Mbits Packet

Protocols	TCP/IP
Security	Static MAC Address Broadcast/Multicast/Unknown Unicast Storm Control
PoE	Yes
QoS	Yes
Layer	2
Port Mirroring	Yes
LEDs	Power (Per Device) Link/Activity/Speed (Per Port) PoE Max.

Meet Your Seller

D-Link 8-Port EasySmart Gigabit PoE Ethernet Switch - Lifetime Warranty (DGS-1100-08P)

Learn more about the D-Link DGS-1100-08P

Customer Reviews of the D-Link DGS-1100-08P

Warranty & Returns

Warranty, Returns, And Additional Information

Return Policies*

Manufacturer Contact Info

Temperature	0°C to 50°C (32°F to 122°F)
Humidity	10% - 95%, Non-condensing

Dimensions & Weight
Dimensions	7.4" x 4.7" x 1.1"
Weight	1.6lbs.

Item#: 9SIAD6H5EE7194
