Question 1

I have dual monitors, what type of connectors would I need to purchase.  My displays use DVI cables?

Accepted Answer

You shouldn't need to purchase any for 2 displays using dvi.   There is one dvi on the card for the first display and it comes with an adapter ( dvi to display port) you can use for he second.  With in the control panel, in cluded in the driver instaltion, you can select primary and secondary.   You can also play with some custom display tuning using other nvidia setup.    This card is pretty awesome.  It's compact which is great for a discreet but moderatley powered work station.  This cards performance vs size was enough to convince me to hold on Even considering k4200 or up.   Until they release Maxwell tech or better I would sooner pair 2 k2200.   This card can also be set to TCC driver mode

Question 2

Does this card have a standard bracket or low profile?

Accepted Answer

Standard.   For nomal instaltion its standard only.   Try k620 for a low profile.   Since I have zero clue what your needs or purpose are for he k2200 I'm not sure if that is a compromise.   I have a k600 and a k420 and 600 as well which are OK cards I have since utilized them in a low pro configuration for a refuburished dells that I now use to control machines.   My k2200 is in my go to work station that Handel's the majority of simplistic tasks for graphic design and cad for machines.    For rendering and major graphics and 3d scanning I use an older ,custom built compture with gtx 960.    The k2200 however is a solid choice compact.  It's quite and perfect for my office work station.  I complimented it with an evo 850.   I can turn the system on log in quick check facebook and list of new emails and fire up the cad in less than 2 minutes

Question 3

is this unit (NVIDIA® Quadro® K2000 VCQK2000-PB 2GB GDDR5 PCI Express 2.0 x16 Workstation Video Card) or the this unit (PNY Quadro K2200 VCQK2200-PB 4GB 128-bit GDDR5 PCI Express 2.0 x16 Workstation Video Card) compatible with the Dell Precision T1700 MT /SSF?

Accepted Answer

I believe so, with up to date drivers. I have utilized it in my Dell Precision T1600. I have tried it alone and in a Multi-gpu configuration with a Quadro 600( While "unsupported" It worked quite well, I belive that's the Maxwell technology. Unfortunately the dell T1600's second PCIe x16 slot is only wired x4 so the only compatible second card I know that will work is the Quadro600, other wise the BIOS fails to post. )

I really Like this card.  Its very stout. Its not as fast as the 750ti with rendering, but its very for CFD it stands to be the best I have tried. Please note the this card and the GTX 750ti are the highest quality I have had to date.

I also discovered that the This card, the Quadro K2200 with Maxwell  architecture supports TCC mode so it can operate as a Tesla device. I look forward to testing this between projects.

Question 4

Anyone know how long this card is?  Customer wants a microATX case but it looks like the fan cover really extends far off the actual card.

Accepted Answer

The card is 4.376" H x 7.97" L Single Slot.

Question 5

Has anyone tested this with Windows 10?  Does the manufacturer say it's compatible with Windows 10?  Under Specifications, all that's listed under 'Operating Systems Supported' is: "Windows, Linux".  Not very reassuring...

Accepted Answer

While Nvidia has not released their final WHQL Windows 10 drivers for the Quadro cards, they are supported and work with Windows 10.

Question 6

How is this even a deal?  You can get better performance for about the same price or better that has 256-bit DDR 5 with the PCI 3.0 lane standard.  Unless, were talking about capability for heritage hardware.  But even under those conditions I wouldn't really call that workstation worthy for Solidworks, or 3D rendering.

Accepted Answer

It's reliability that I'm after, this is not meant for everyday video game or low level CAD use. 3D rendering is only part of what I do, I run finite element analysis that really tortures the Video card. This is meant for professional use, if you don't do tasks that are demanding or if you don't need the reliability, then you will have more value for your money if you don't buy a workstation card. Check out GeForce vs Quadro video on YouTube by Techquikie, Linus explains it really well.

Question 7

Is this a 10 bit card, that can run 10 bit monitors with DP?

Accepted Answer

Yes, the K2200 supports 30-bit color (10-bits per channel)

Question 8

Does this card require a computer that has UEFI bios?

Accepted Answer

no

Question 9

Will this card work in a 5 year old MOBO (Gigabyte GA-P55-UD4P) ?

Accepted Answer

It will work well as long as the motherboard supports PCI Express 2.0.

Question 10

I have a Quadro 2000 in my Precision T3600. Can I add a Quadro 2200 and take advantage of having two cards? Or do I have to add another Quadro 2000? And should I do that as opposed to using a single new Quadro 2200?

Accepted Answer

Since SLI isn't available it shouldn't be a problem to add the K2200. Running two graphics card not in SLI sync will allow you to have more monitors not really more power.  Programs will only utilize the graphics card that the program is displayed upon. The k2200 does have more power than your k2000 but a higher grade card like the k4200 will out perform easily two k2200's.

GPU Memory	4GB GDDR5
Memory Interface	128-bit
Memory Bandwidth	80.0GBps
NVIDIA CUDA® Cores	640
System Interface	PCI Express 2.0 x16
Max Power Consumption	68W
Thermal Solution	Ultra-Quiet Active Fansink
Form Factor	4.376 H x 7.97" L, Single Slot, Full Height
Display Connectors	DVI-I DL + 2x DP 1.2
Max Simultaneous Displays	3 direct, 4 DP 1.2 Multi-Stream
Max DP 1.2 Resolution	3840 x 2160 at 60Hz
Max DVI-I DL Resolution	2560 x 1600 at 60Hz
Max DVI-I SL Resolution	1920 x 1200 at 60Hz
Max VGA Resolution	2048 x 1536 at 85Hz
Graphics APIs	Shader Model 5.0, OpenGL 4.5, DirectX 11.2
Compute APIs	CUDA, DirectCompute, OpenCL™

Chipset Manufacturer	NVIDIA
GPU	Quadro K2200
CUDA Cores	640

DirectX	DirectX 11
OpenGL	OpenGL 4.4

Digital Resolution	Maximum DP 1.2 Resolution: 3840 x 2160 at 60Hz (direct connect) Maximum DVI-I DL Resolution: 2560 x 1600 at 60Hz Maximum DVI-I SL Resolution: 1920 x 1200 at 60Hz
Analog Resolution	Maximum VGA Resolution: 2048 x 1536 at 85Hz
Max Displays Per Board	4
3D Vision Pro	Yes (via USB connection to 3D Vision hub)
Cooler	Ultra-quiet active fansink
Dual-Link DVI Supported	Yes
HDCP Ready	Yes
Operating Systems Supported	Microsoft Windows 8.1, 8, 7, Vista, Linux, or Solaris
System Requirements	Maximum Power Consumption: 60W PCIe x16 expansion slot 2GB or more of system memory, 8GB recommended 200MB of available disk space for full driver installation Blu-ray or DVD-ROM drive Internet connection (if preferred for driver installation) DisplayPort, DVI, or VGA compatible display(s)

Form Factor	Plug-in Card
Dimensions (L x H)	7.97" x 4.38"

Meet Your Seller

PNY Quadro K2200 VCQK2200-PB 4GB 128-bit GDDR5 PCI Express 2.0 x16 Plug-in Card Graphics Card

Accelerate your creativity with NVIDIA® Quadro® – the world’s most powerful workstation graphics.

Features

NVIDIA Quadro K2200 – Amazing 3D Application Performance and Capability

Learn more about the PNY Technologies, Inc. VCQK2200-PB

Customer Reviews of the PNY Technologies, Inc. VCQK2200-PB

Warranty & Returns

Warranty, Returns, And Additional Information

Return Policies*

Manufacturer Contact Info

Ports
DisplayPort	2
DVI	1 x DL-DVI-I

Item#: 9SIB1PGFBY9497
