TYAN Combo Deal, S8030GM2NE ATX Server Motherboard Installed AMD EPYC 7252, 8 Cores, 16 Threads, 3.2GHz, 120W. Factory Installed/Tested/Burn-in/Shipped

CPU: Installed 2X AMD EPYC 7252, 8 cores, 16 threads, 3.2G, 120W.
AMD "Rome" Platform based on the EPYC 7003/7002 processor. Features support for PCIe Gen 4.0, DDR4-3200, and CPU TDP up to 280W all in a 12x9.8" ATX form factor. Low loss PCB & no PCIe redriver/retimer chips for a low cost PCIe Gen 4.0 solution.
AMD EPYC 7002 and 7003 Processor /w TDP up to 280W
Memory
(8) DDR4 DIMM slots (8 memory channels)
Supporting up to 2TB RDIMM/LRDIMM/NVDIMM DDR4-3200
PCIe Expansion Slots
(5) PCIe Gen 4.0 x16 slots
Network
(2) 1000Base-T LAN Ports (Intel i210)
(1) 1000Base-T Dedicated IPMI Port (Realtek TRL8211 PHY)
Storage
(12) SATA 6G ports across 3x SFF-8643 MiniSAS HD connectors
(2) SATA 6G ports in 7-pin SATA connectors
(4) PCIe Gen 4.0 NVMe ports across two 74P Slimline connectors
(2) 2280/22110 PCIe Gen 3.0 x4 NVMe M.2 ports
Optional TPM 1.2 & 2.0 modules
AST2500 BMC /w IPMI, iKVM, and Redfish Support

Specs

Reviews

Model
Brand	TYAN
Model	S8030GM2NE-7252

Supported CPU
CPU Socket Type	Socket SP3
CPU Type	Supports AMD EPYC 7002/7003 (with AMD 3D V-Cache Technology) Series Processor
Number of Processor Support	1
CPU Features	Bundled with AMD EPYC 7252 (8 Cores, 16 threads, 3.10 GHz)

Memory
Number of DDR4 Slots	8 x 288-pin
DDR4 Standard	DDR4 3200
Maximum Memory Supported	Up to 512GB RDIMM/ 1,024GB LRDIMM/ 2,048GB LRDIMM 3DS *Follow latest AMD DDR4 Memory POR
ECC Supported	Yes

Expansion Slots
PCI Express 4.0 x16	5

Storage Devices
SATA	(2) SATA / (3) SFF-8643 for (12) SATA ports
M.2	Connector (M.2): (2) 22110/2280 (by PCIe & SATA interface) Connector (U.2): (2) SFF-8654 for (4) NVMe ports

Onboard Video
Onboard Video Chipset	Aspeed AST2500

Rear Panel Ports
Back I/O Ports	USB: (2) USB3.1 Gen.1 ports (@ rear) COM: (1) header VGA: (1) D-Sub 15-pin VGA port (@ rear) RJ-45: (2) GbE ports + (1) GbE dedicated for IPMI Front Panel: (1) 2x12-pin SSI front panel header + (2) 1x2 header SATA: (2) SATA-III connectors / (12) SATA ports from (3) Mini SAS HD connectors Power: ATX 24-pin + (2) 8-pin power connectors

Dimensions
Form Factor	ATX
Dimensions (W x L)	12" x 10"
