Wenglor Photoelectronic Sensors WM03NCT2 NPN New
Working Range 12...18 mm
Working Distance 15 mm
Resolution 20 Gray Scale
Switching Hysteresis < 2 %
Light Source White Light
Wavelength 400...700 nm
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Light Spot Diameter 1,5 × 2,5 mm
?
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 30 mA
Switching Frequency 5 kHz
Response Time 100 µs
Off-Delay 20 ms
Off-Delay (RS-232) 0...2 s
Temperature Drift < 2 %
Temperature Range -25...60 °C
Switching Output Voltage Drop < 2,5 V
NPN Switching Output/Switching Current 100 mA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Lockable yes
Teach Mode ZT, FT
Protection Class III
Setting Method Teach-In
Housing Material Plastic
Full Encapsulation yes
Degree of Protection IP67
Connection M12 × 1; 4-pin
NPN NO/NC switchable yes
RS-232 with Adapterbox yes
MTTFd (EN ISO 13849-1) 2164,07 a
Working Range 12...18 mm
Working Distance 15 mm
Resolution 20 Gray Scale
Switching Hysteresis < 2 %
Light Source White Light
Wavelength 400...700 nm
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Light Spot Diameter 1,5 × 2,5 mm
?
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 30 mA
Switching Frequency 5 kHz
Response Time 100 µs
Off-Delay 20 ms
Off-Delay (RS-232) 0...2 s
Temperature Drift < 2 %
Temperature Range -25...60 °C
Switching Output Voltage Drop < 2,5 V
NPN Switching Output/Switching Current 100 mA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Lockable yes
Teach Mode ZT, FT
Protection Class III
Setting Method Teach-In
Housing Material Plastic
Full Encapsulation yes
Degree of Protection IP67
Connection M12 × 1; 4-pin
NPN NO/NC switchable yes
RS-232 with Adapterbox yes
MTTFd (EN ISO 13849-1) 2164,07 a
