Asrock Rack 1U4LW-X570/2L2T RPSU 1U Rackmount Server Barebone AMD AM4 Ryzen PGA 1331 X570 4x3.5 HDD 450W Redundant Power Supply Dual 10G

Be the first to review this product...
  • 1U Rackmount with 450W RPSU, 100-240V, 50-60Hz
  • Support AMD Ryzen 5000 Series Desktop Processors
  • Support 4 x DIMM slots, DDR4 288-pin ECC and non-ECC UDIMM, up to 32GB per DIMM
  • Support 4 x Hot-swap 3.5" HDD/SSD bays + 3 x fixed 2.5" HDD/SSD bays
  • Support 1 x PCIe 4.0 x16 full height half length card (by Riser card)
  • Support 2 x RJ45 10GbE RJ45 by Intel X710-AT2+ 2 x RJ45 1GbE by Intel i210 + 1 x Dedicated IPMI LAN
  • General-purpose Server
+
+
Specs
Reviews

Learn more about the ASRock Rack 1U4LW-X570/2L2T RPSU

General
Brand ASRock Rack
Model 1U4LW-X570/2L2T RPSU
Form Factor 1U Rackmount
Workload General Purpose Server
CPU Supported
CPU Type AMD Ryzen 5000 Series Desktop Processors
AMD Ryzen 4000 G-Series Desktop Processors with Radeon Graphics
AMD Ryzen PRO 4000 and 3000 Series Desktop Processors
AMD Ryzen 3rd Gen Desktop Processors
AMD Ryzen 3000 Series Processors with Radeon Graphics
CPU Socket AM4
Chipset
North Bridge AMD X570
Memory Supported
Memory Slots 4 x 288Pin
Installed Memory Size No Memory Installed
Memory Type Supported Up to DDR4 3200 MHz*

* AMD Ryzen 3000 Series Processors with Radeon Graphics support up to 2666 MHz
Storage Supported
Installed HDD No Storage Installed
Graphics
GPU/VPU Aspeed AST2500
Video Memory 16MB DDR4
Expansion Slots
PCI Express Supports 1 FHHL (PCIe4.0 x16)* via RB1UX16_G4

*Supports PCIe3.0 x8 when using AMD Ryzen 3000 Series Processors with Radeon Graphics
Communications
First LAN Intel X710-AT2
Second LAN Intel I210
Max. LAN Speed 10 Gigabit + 1 Gigabit
Expansion Bays
Hot-Swap Bays 4 x Hot-swap 3.5" HDD/SSD (SATA 6Gb/s) bays
Panel Ports
COM 1
VGA 1
Rear USB 2 x USB 3.2 Gen 2
RJ45 2 x RJ45(10GbE) by Intel X710-AT2
2 x RJ45(1GbE) by Intel i210
Power Supply
Max. Power 450W, 80-Plus Platinum, 100-240V, 50-60Hz
Features
Features 1U Rackmount with 450W RPSU
supports AMD Ryzen 5000 Series Desktop Processors
4 DDR4 ECC/ non-ECC UDIMM, up to 32GB each
4 Hot-swap 3.5'' HDD/SSD bays, 3 fixed 2.5" HDD/SSD bays
1 FHHL PCIe 4.0 x16
On-board dual 10GbE RJ45 and dual 1GbE RJ45
Remote management (IPMI)
Dimensions & Weight
Dimensions 1.75" x 21.00" x 19.00"
Additional Information
Date First Available February 05, 2021
