2 x Front USB-A 3.2 Gen 1 1 x Front USB-C 3.2 Gen 2 1 x Audio/Mic Jack Front Ports
2 Internal 3.5" Drive Bays
+
+
Overview
Specs
Reviews (47)
A marvel of modern design, the Y70 Dual Chamber Modern Aesthetic Panoramic Tempered Glass EATX Mid-Tower Computer Case in striking red, is a sophisticated upgrade for any gaming setup. This dual chamber ATX mid-tower case is designed to deliver an unparalleled gaming experience, boasting a massive 4-slot vertical graphics capacity and an expansive cooling system. The Y70's unique design allows for an impressive display of your hardware, showcasing your PC in all its glory. The 4-slot vertical graphics support is enhanced with additional airflow space between the card and the glass, accommodating even the most powerful graphics cards with ease.
The case also features a cold floor cooling system, capable of housing up to three 120mm or two 140mm fans, up to 32mm thick. This system directs fresh airflow straight into the GPU, ensuring optimal performance. Included with the Y70 is a luxury PCIE 4.0 x 16 riser cable, complete with a color-matched canopy for a seamless visual flow. This feature simplifies the GPU installation process and allows for a variety of half-height PCIE cards to sit behind the vertical graphics. The Y70's cooling capacity is truly exceptional, with a spacious interior that can accommodate a 360mm long & 125mm thick radiator on the side, and an adjustable top bracket for another 360mm radiator up to 68mm thick.
With a total capacity of 10 fans in a fully populated chassis, and over 180mm of clearance to the side glass, this case offers unparalleled flexibility for air and water cooling configurations. The Y70's modern aesthetic is unified across four unique colorways, putting your build front and center with a beautifully crafted 3-piece panoramic glass window. The dual chamber interior layout provides ample space for cable management, aided by a seamless L-shaped molded rubber grommet, meticulously placed cable routing channels & tie-down points, and reusable Self-Securing Closure straps. The Y70 also features tool-less top and side panels, alongside floating storage sleds that eject from the rear of the case for intuitive drive maintenance.
This mid-tower computer case is not just a housing for your PC, but a statement of style and performance.
Learn more about the HYTE CS-HYTE-Y70-BR
Model
Brand
HYTE
Series
Y70
Model
CS-HYTE-Y70-BR
Details
Type
ATX Mid Tower
Color
Black / Red
Case Material
ABS / Steel / Tempered Glass
Motherboard Compatibility
ATX / E-ATX / Micro ATX / Mini ITX
Dust Filters
Bottom / Side / Top
Expansion
Internal 3.5" Drive Bays
2
Internal 2.5" Drive Bays
4
Expansion Slots
4 Vertical, 7 Half-Height
Front Panel Ports
Front Ports
2 x USB-A 3.2 Gen 1, 1 x USB-C 3.2 Gen 2, 1 x Audio,
Cooling System
Fan Options
Top: 3x120mm or 2x140mm Side: 3x120mm or 2x140mm Rear: 1x120 or 1x140mm Bottom: 3x120mm or 2x140mm Fans up to 32mm thick
Radiator Options
Top: up to 360mm or 280mm long & 68mm thick Radiator Side: up to 360mm or 280mm long & 125mm thick Radiator Rear: 120mm or 140mm Radiator
Dimensions & Weight
Max GPU Length
422 mm
Max CPU Cooler Height
180 mm
Max PSU Length
235 mm
Dimensions (H x W x D)
470mm (L) x 320mm (W) x 470mm (H)
Additional Info
Features
Dual chamber interior layout so you can showcase the build up front with space to manage cables in the back
4 slot vertical graphics to accommodate even the largest and most powerful of GPUs into your build with ease
Included luxury PCIE 4.0 x 16 riser with a color matched canopy for uninterrupted visual flow
7 half-height horizontal PCIe slots which provide ample room for additional hardware expansion
Seamless L-shaped molded rubber grommet that disappears into the case for a cohesive look
