Delta FFB0912SH-F00 92mm Case Cooler
- 92mm
- 4100 RPM 90.02 CFM
- Dual Ball
- 50 dBA
+
+
Specs
Reviews (22)
Learn more about the DELTA ELECTRONICS FFB0912SH-F00
| Brand | Delta |
|---|---|
| Model | FFB0912SH-F00 |
| Type | Case Fan |
|---|---|
| Compatibility | Case |
| Fan Size | 92mm |
| Bearing Type | Dual Ball |
| RPM | 4100 RPM |
| Air Flow | 90.02 CFM |
| Noise Level | 50 dBA |
| Power Connector | 3-pin (TAC output) Rated Voltage : 12V Operating Voltage Range : 7 ~ 13.8V Input Current : 0.69 Amp Input Power : 8.28 Watt Maximum Air Pressure : 10.06 mm H²O |
| Color | Black |
| Features | Rated Voltage: 12 VDC Operating Voltage Range: 7 - 13.8 VDC Input Current: 0.69 Amp (Maximum 1.04A) Input Power: 8.28W (Maximum 12.48W) Maximum Air Pressure: 10.06 mmH2O or 0.396 inchH2O The Delta FFB0912SH-F00 is a medium high speed cooling fan at 92 x 92 x 25mm. It yields an air flow of 90.05 CFM at 4100 RPM, or 2.55 cubic meter per minute, at 50 dBA. Life expectance is 70,000 hours (or almost 16 years if you operate the fan 12 hours a day) at 40 Degree C with 15 - 65% RH, all thanks for industrial grade materials plus top notched, high quality dual ball bearing. Operating temperature is -10 to +60 Degree C with 5 - 90% RH. Protection includes Over Current Shut-Down Protection when rotor is locked, and Polarity Protection which can withstand reverse connection on positive and negative leads. This fan does not contain ozone depleting substances such as PBBs, PBBOs, CDCs, PBBEs, PBDPEs and HCFCs. This fan has 3 wires lead with fan speed sensor output, and is wired with a 3 pin fan connector. You can power the fan by fan 3 pin headers on most computer motherboards, or by fan controllers through the 3 pin connector of the fan. You can also power the fan through a Molex 4 pin connector from a common computer power supply with a 3 pin to Molex 4 pin cable adapter (sold separately). Wire lead is approximately 12 inches long. |
|---|
| Dimensions | 92.00 x 92.00 x 25.00mm |
|---|
| First Listed on Newegg | October 10, 2023 |
|---|
