Specifications: Adapter Style: Cable Adapter
Audio: No
Cable Jacket Type : PVC - Polyvinyl Chloride
Connector Plating: Gold
Converter Type: Passive
System and Cable Requirements: DP++ (DisplayPort++) port is required on video card or video source for DVI and HDMI pass-through.
Specifications: Color: Black
Maximum Digital Resolutions: 1920 x1200 / 1080p
Cable Jacket Type: PVC - Polyvinyl Chloride
Packaging Style: Bagged
*Requires DP++ (DisplayPort++) port from video card or video source.
Specifications: Active or Passive Adapter: Passive
Audio: No
Cable Jacket Type: PVC - Polyvinyl Chloride
Connector Plating: Gold
Performance
Maximum Digital Resolutions: 1920x1200 / 1080p
Special Notes / Requirements
Note: DP++ (DisplayPort++) port is required on video card or video source for DVI and HDMI pass-through.
Environmental
Humidity: 10~85% RH
Operating Temperature: 0~45 celsius degree
Storage Temperature: -10~80 celsius degree
Specifications: Converter Type: Passive
Audio Specifications: 5.1 Surround Sound
Maximum Digital Resolutions: 1920 x 1200 / 1080p
System and Cable Requirements: DP++ port (DisplayPort ++) required on video card or video source (DVI and HDMI pass-through must be supported)
Specifications: Audio Specifications: HDMI output - 7.1 surround sound; DVI output - 2-channel stereo audio
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 × 2160
Maximum Power Delivery Support: None
Supported Resolutions: HDMI output: 3840 x 2160 (@ 30 Hz), 2560 x 1600, 2048 x 1280 (@ 60 Hz), 1920 x 1200, 1920 x 1080, 1280 x 720; VGA and DVI output: 1920 x 1200 (@ 60 Hz), 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Output Connector: 1 x HDMI (19 pin) Female Output
1 x DVI-I (29 pin) Female Output
1 x VGA (15 pin, High Density D-Sub) Female Output
