16 Gigabit auto negotiation RJ45 ports greatly expand network capacity
10KB Jumbo frame improves performance of large data transfers
Supports MAC address auto learning and auto aging
Auto MDI/MDIX eliminates the need for crossover cables
Innovative energy efficient technology saves power consumption
Plug and play, no configuration needed
+
+
Overview
Specs
Reviews (118)
16 10/100/1000M RJ45 ports.Metal case. Innovative energy-efficient technology saves power up to 40%. Supports MAC address self-learning, Auto MDI/MDIX and Auto negotiation. Plug and Play design.
Learn more about the TP-Link TL-SG1016D
Model
Brand
TP-Link
Model
TL-SG1016D
Format & Standards
Format
Desktop/Rackmount
Standards
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network Management Type
Unmanaged
Ports & Interface
Uplink Ports
16
Uplink Interface
RJ45
Primary Ports
16 x RJ45
Primary Port Speed
10/100/1000Mbps
Data Transmission
Switching Method
Store and Forward
Jumbo Frames
10KB
Details
Protocols
TCP/IP
PoE
No
Layer
Layer 2 Only
Power
100~240VAC, 50/60Hz
Features
Features
Innovative energy-efficient technology saves power up to 40%
Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
32Gbps Switching Capacity
10K Jumbo frame improves performance of large data transfers
Auto-MDI/MDIX eliminates the need for crossover cables
Supports MAC address auto-learning and auto-aging
Store and forward Switching scheme
Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware.
