The RocketRAID 4321 from HighPoint offers a new level of flexibility and performance to servers and workstations by supporting either 15,000 rpm SAS hard drives for performance or lower cost SATA hard drives for capacity. Supporting RAID 0, 1, 3, 5, 6, 10, 50 and JBOD, it can not only backup data but can also extend the storage capacity of a system significantly.
It supports the industry’s fastest bus speeds at PCI-Express X8 and offers complete connectivity with 1 external and 1 internal mini-SAS connectors. Using SAS expanders, it can connect up to 128 SAS devices.
Based on the Intel IOP348 I/O processor and HighPoint's TerabyteArchitecture, this high-performance PCIe-to-SAS RAID host adapter delivers enterprise-class SAS RAID 5 and RAID 6 performance for mission critical applications that require high sustained performance, availability and native expansion.
The RocketRAID 4321 from HighPoint offers a new level of flexibility and performance to servers and workstations by supporting either 15,000 rpm SAS hard drives for performance or lower cost SATA hard drives for capacity. Supporting RAID 0, 1, 3, 5, 6, 10, 50 and JBOD, it can not only backup data but can also extend the storage capacity of a system significantly.
It supports the industry’s fastest bus speeds at PCI-Express X8 and offers complete connectivity with 1 external and 1 internal mini-SAS connectors. Using SAS expanders, it can connect up to 128 SAS devices.
Based on the Intel IOP348 I/O processor and HighPoint's TerabyteArchitecture, this high-performance PCIe-to-SAS RAID host adapter delivers enterprise-class SAS RAID 5 and RAID 6 performance for mission critical applications that require high sustained performance, availability and native expansion.
Serial Attached SCSI InterfaceWith one internal and one external mini-SAS (Serial Attached SCSI) ports, the HighPoint RocketRAID 4321 supports both 3.0 Gb/s SAS and SATA II devices for enhanced flexibility and speed.
RAID SupportThe HighPoint RocketRAID 4321 supports multi-level RAID configuration including RAID 0, 1, 3, 5, 6, 10, 50 and JBOD for better performance, enhanced data security and flexible capacity upgrades.
On-board I/O ProcessorThe HighPoint RocketRAID 4321 features an integrated 1.2GHz Intel IOP348 processor for fast hardware RAID parity calculations.
512MB Cache Memory with ECC Protection512MB of DDR2 533 SDRAM with ECC protection is integrated into the HighPoint RocketRAID 4321 for maximum data integrity.
PCI Express x8 InterfaceCompatible with PCI Express x16 slot, the PCI Express x8 interface provides sufficient throughput and full-duplex operation for enhanced performance.
Learn more about the HighPoint Technologies, Inc. RocketRAID 4321
Model
Brand
HighPoint
Model
RocketRAID 4321
Form Factor
Low Profile
Details
Type
SATA / SAS
External Connectors
1 x SFF-8088 mini-SAS
Internal Connectors
1 x SFF-8087 mini-SAS
Interface
PCI-Express x8
Transfer Rate
Up to 3Gb/s
Cache Memory
512MB DDR2
RAID
RAID 0/1/3/5/6/10/50 JBOD
Operating Systems Supported
Microsoft Windows 2008/2003/XP/2000, Vista 32 and 64 bit WHQL Certified Windows (2003/2008, Vista 32 and 64bit) Red Hat Enterprise Linux, Open SuSE, Fedora Core, Debian, Ubuntu, FreeBSD Mac OS X Linux driver embedded into kernel 2.6.25 and higher Vmware ESX/ESXi 4.0 and 4.0 U1
Dimensions
6.57"L x 2.68"W
Features
Features
Intel IOP348 (1.2GHz)
1 external and 1 internal mini-SAS/SATA 3Gb/s Device connectors
Up to 8 SAS/SATA Hard Drives 128 max hard drives via SAS expanders
NCQ (Native Command Queuing)
NVRAM
Battery Backup Unit Ready (BBU-03)
Additional Information
Date First Available
April 20, 2009
