Question 1

what is the maximum capacity of this using all four slots? could I use 4x2tb drives?

Accepted Answer

Yes, that’s how I’m using it; 4x 960 Pro 2TB in Raid 0. I built a benchmarking script to test every setup possible (including mounting options) and get about 7-8GB/sec (big B) read, 5-6GB write.

Question 2

How loud is the fan? Can you even hear it?

Accepted Answer

Yes you can here it. ITs annoying as hell. In a server room, you wont hear it, but if its a desktop, it's loud.

Question 3

Can you boot to this device?

Accepted Answer

I wish.   I just returned mine.   I also can't use no intel drive or else I can only do their (hpt) raid 0 non bootable.   It will not do any other raid but 0 unless you don't use the (hot) driver and the. Ms soft raid.  This is not ready for prime time yet.  Do not buy IMO.   daz

Question 4

What operating systems are compatible with the HighPoint SSD7101A-1 RAID Controller?

Accepted Answer

The HighPoint SSD7101A-1 RAID Controller is compatible with Windows 10, Windows Server 2012 R2 or later, Linux Kernel 3.3 or later, and macOS 10.13 or later.

Question 5

What is the maximum data transfer rate supported by the SSD7101A-1 RAID Controller?

Accepted Answer

The SSD7101A-1 RAID Controller supports data transfer rates of over 12,000MB/s.

Question 6

Does the motherboard needs to support pci bifurcation for it to be able to see all drives? Can it work in a x16 (size) slot but with only x8 lanes

Accepted Answer

I am currently using an asus x99 ws 10g motherboard, they are traces on the cards pcb that link to pcie pins, so i would assume that 2 rear slots within the card will be disabled if you slot is oy pinned for x8.

Question 7

Is this thing bootable in Windows 10 yet?

Accepted Answer

Kind of.... If you are using X299 chipset and buy a VROC dongle you can boot from it, however, if you use Threadripper the ability to boot from it in RAID is free. I am currently using 3 of these with 960 Evo's in Raid 10.

Question 8

can I intall windows with this card by using raid config?

Accepted Answer

See my post(s) below.  Daz
