Intel RS3WC080 PCI-Express 3.0 x8 Low Profile Ready SATA / SAS Controller Card
- RAID 0/1/5/10/50
- 8 x SAS Internal Connectors
- Up to 12Gb/s
Intel® RAID Controller Card
Model: RS3WC080
Overview
Intel Corporation designs and builds the essential technologies that serve as the foundation for the world's computing devices. The Intel® RAID Products are built on a foundation of industry leading quality and innovation to support the Intel® Xeon® processor family.
The Intel® RAID Controller RS3WC080 is a mid-tier product that includes firmware powered by LSI MegaRAID technology and offers many of the same features as Intel's mainstream RAID products.
- Architected with a LSI3008 I/O controller which allows for good RAID performance with a small number of hard drives (fewer than 8)
- Hardware RAID 0,1,10 and Firmware-based Hybrid RAID 5 provide flexibility in performance and data protections
- Advance management tools deliver capabilities typically found in higher end (ROC-based) products
Technical Specifications
| Model#
|
RS3WC080
|
| Target Market |
Entry |
| Board Form Factor |
Low Profile MD2 |
| Data Transfer Rate |
12 Gb/s |
| Supported Devices |
SAS/SATA |
| RAID Level Supported |
0,1,10,5,50 |
| # of Ports Internal |
8 |
| # of Ports External |
0 |
| # of Devices Supported |
128 |
| PCIe Host Interface |
x8 PCIe Gen3 |
| IO Processor Model |
LSI3008 IOC |
| Included Items |
One RAID adapter with full and low profile brackets |
Intel RAID Controller RS3WC080, Single - Description: 12Gb/s SAS, 6Gb/s SATA, LSI3008 IOC-based entry-RAID 0,1,10 and hybrid RAID 5/50, x8 PCIe 3.0, 8 internal ports, MD2 Low Profile, half-length form factor. Full height (installed) and low profile bracket included Board Form Factor: Low Profile MD2 Data Transfer Rate: 12 Gb/s Supported Devices: SAS & SATA RAID Level Supported: 0,1,10,5,50 # of Ports Internal: 8 # of Ports External: 0 # of Devices Supported: 128 PCIe Host Interface: x8 PCIe Gen3 IO Processor Model: LSI3008 IOC Connector Orientation: Side Extended Warranty Available for Purchase (Select Countries) - Yes Included Items: One RAID adapter with full and low profile brackets
