Intel RAID Controller Card 3G SATA/SAS PCI-E x4 4 internal ports (SASWT4I)

Name: Intel SASWT4I PCI Express x4 SATA / SAS Controller Card
Brand: Intel
SKU: N82E16816117158
Rating: 4 (7 reviews)

(7) Write a Review

RAID 0/1/1E/10E
Four SATA x1 Internal Connectors
Up to 3Gb/s

Overview

Specs

Reviews (7)

Any questions? Our AI beta will help you find out quickly.

Try me now

The economical Intel RAID Controller SASWT4I offers exceptional entry-level hardware SAS/SATA RAID and non-RAID data off-load for server systems and workstations. This RAID controller allows for point-to-point connections with a SAS universal interconnect interface. This allows for 1.5 and 3 Gb/s SATA hard disk drives, along with logical SCSI compatibility for the extra reliability and manageability that SAS drives provide.

Cost-effective Data ProtectionThis adapter provides a low-cost RAID 0, 1, and 1E/10E solution for entry-level server and workstation environments where high-performance and reliable data protection are required.
SAS or SATA StorageConnect SAS or SATA devices within the array. Use SAS drives for speed, reliability and scalability and use high-capacity SATA drives for budget-friendly storage.
FlexibilitySupports up to 122 physical devices in SAS mode. This is ideal for employing JBODs (Just a Bunch Of Disks) or up to 14 devices in RAID 0, 1, 1E/10E mode through direct connect device attachment or through expander backplane support.
Ultra-thin DriverLSI Fusion-MPT architecture provides over 140,000 I/Os per second while communicating over the PCI Express 4-lane Host Bus.
Hot SpareIncludes global hot spare support that automatically comes online to replace the first drive to fail on any array or disk group on the controller.
