HPL 750W 120V 300HR Stage & Studio 750/120 Lamp 54605 - UCF design, high lumen output, reinforced pinch seal, top bridgeless construction, special heat sink base for durability

Product features and benefits-Ultra compact filament design (UCF) for high lumen output-Unique top bridgeless construction improves beam uniformity for lamps with 120 volts-Unique gas fill which improves light output and minimizes risk of arc-out-Special heat sink base for maximum durability in high temperature applications-Reinforced pinch seal for extra mechanical strength-Foam packaging for easier handling and installation-Optimum system performance with TP22H socket - Areas of application-Stage and theatre-Studio, TV and film-Architecture Architainment - Technical Data - General product information - Product Number - 54605 - Product Name - HPL750120 (UCF) 120V 12/CS 1/SKU - Ordering Abbreviation - HPL 750/120 (UCF) - General Description - 750 watt, tungsten halogen, HPL series - Application - Stage Studio - Electrical data - Nominal Wattage - 750 W - Nominal Voltage - 120 V - Type of Current - AC - Light technical data - Luminous Flux - 21900 lm - Light Center Length - LCL (in) - 2.352 in - Light Center Length - LCL (mm) - 60.3 mm - Color Temperature - 3250 K - Color Rendering Index - 100 - Average Rated Life - 300 h - Physical attributes - Base - G 9.5 with Heat Sink - Bulb Shape - T6 - Maximum Overall Length (in) - 4.1 in - Maximum Overall Length (mm) - 104 mm - Length l (in) - 4.1 in - Length l (mm) - 104 mm - Length l max.

(in) - 4.1 in - Length l max. (mm) - 104 mm - Diameter d (in) - 0.748 in - Diameter d (mm) - 19.00 mm - Distance a (in) - 2.352 in - Distance a (mm) - 60.3 mm - Filament - 4-C8 - Reflector Coating - 19.00 - Additional product data - Operating Position - Any - Class - C (gas) - Lamp Type - SINGLE END -
