JetWay JXBLUE-78GA3-LF AM3/AM2+/AM2 AMD 780G HDMI ATX AMD Motherboard

(6) Write a Review
OUT OF STOCK.
  • AMD 780G
  • Phenom / Athlon 64 X2 / Athlon 64 FX / Athlon 64 / Sempron
  • DDR3 1333 / DDR2 1066
Specs
Reviews

Learn more about the JETWAY JXBLUE-78GA3-LF

Model
Brand JetWay
Model JXBLUE-78GA3-LF
Supported CPU
CPU Socket Type AM3/AM2+/AM2
CPU Type Phenom / Athlon 64 X2 / Athlon 64 FX / Athlon 64 / Sempron
Chipsets
Chipset AMD 780G
South Bridge AMD SB700
Memory
Number of Memory Slots 2x240-pin DDR2 + 2x240-pin DDR3
Memory Standard DDR3 1333 / DDR2 1066
Maximum Memory Supported 4GB(DDR2) / 4GB(DDR3)
Channel Supported Dual Channel
Expansion Slots
PCI Express 2.0 x16 1 x PCI Express x16 slot by 16-lane
1 x PCI Express x16 slot by 4-lane
PCI Express x1 1 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
PATA 1 x Ultra DMA 133 / 100 / 66 IDE connector for 2 IDE devices
SATA 3Gb/s 6 x SATA 3Gb/s
SATA RAID 0/1/10/JBOD
Onboard Video
Onboard Video Chipset ATI Radeon HD 3200
Onboard Audio
Audio Chipset Realtek ALC662
Audio Channels 6 Channels
Onboard LAN
LAN Chipset Realtek RTL8111CVC
Max LAN Speed 10/100/1000Mbps
Rear Panel Ports
PS/2 2
Video Ports D-Sub + DVI
HDMI 1 x HDMI
USB 1.1/2.0 4 x USB 2.0
Audio Ports 3 Ports
Internal I/O Connectors
Onboard USB 2 x USB 2.0/1.1 headers for 4 USB 2.0/1.1 ports
Physical Spec
Form Factor ATX
Power Pin 24 Pin
Features
Features Advanced Power Design that supports the latest Socket-AM3 CPU
Onboard DDR2 64MB sideport memory
Support G.P.I Technology
Support WI-FI Technology
Additional Information
Date First Available June 09, 2009

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 2 years
  • Limited Warranty period (labor): 2 years
